High Efficient HZS120 Stationary Precast Concrete Batching Plant
- Qingdao Shanghai
- T/T
You May Like
-
HZS50 Stationary Fully Automatic RMC Plant For Sale
-
Hot Sale YHZS Series Mobile RMC Plant For Sale
-
Hot Sale YHZS Series Modular Type Mobile Concrete Mixer Plant
-
Popular Low Cost Stationary Precast Planetary Concrete Mixer Plant
-
2016 New Design High Reliability Precast Concrete Batching Plant Price
-
High Efficient Belt Conveyor Concrete Mixing Plant With Concrete Mixer Silo
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Henan, China | Brand Name | DASWELL | |
| Model Number | HZS 120 | Power(W) | 210 KW | |
| Dimension(L*W*H) | 55885x20200x21600 mm | Weight | 50 Ton | |
| Certification | ISO 9001-2008,CE | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Technical Parameters |
Model | HZS25 | HZS35 | HZS50 | HZS60 | HZS90 | HZS120 | HZS180 | |
Capacity (m3/h) | 25 | 35 | 50 | 60 | 90 | 120 | 180 | |
Mixer | JS500 | JS750 | JS1000 | JS1000 | JS1500 | JS2000 | JS3000 | |
Aggregate batcher | PLD1200 | PLD1200 | PLD1600 | PLD1600 | PLD2400 | PLD3200 | PLD4800 | |
Discharge height (m) | 3.8 | 3.8 | 3.8 | 3.8 | 3.8 | 4 | 4 | |
Cycle time (s) | 60 | 60 | 60 | 60 | 60 | 60 | 60 | |
Weighing accuracy | Aggregate | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 |
Cement | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 | |
Water | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 | |
Additive | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | |
| Brief Introduction |
HZS series stationary concrete batching plant is widely used in big or medium building projects, road and bridges projects, precast concrete plants, etc. It is an ideal choice for producing commercial concrete.
HZS series stationary concrete batching plant has two feeding methods. One is hopper type, it is used for lower than 50m3 per hour output production. The other is belt type, it is often used for higher than 60m3 per hour output production.
For export, we adopt full automatic control system for our stationary concrete mixing plant. It is PC+PLC control, which can vividly display the production process on the screen, so that the operator can monitor in real time.
| Features |
| Packaging and Shipping |
| Our Services |
| About Us |
Daswell Machinery is a company specializing in the research, design and production of construction for nearly 30 years.Our main products are construction machinery, such as concrete mixer, concrete batching plant, concrete pump, and so on.
With several researching and producing bases in China, we can provide the powerful technical service and upper quality machinery for the clients all over the world. All of our products are produced according to the International Quality Standards, such as CE from Europe. The management of our company is strictly operated by the ISO 9001 quality management system.
And also,we supply the famous brand concrete machinery and related parts,such as SICOMA,and WAM Brand.We have supplied so much famous brand machinery and parts to many countries of the world.
All of our Daswell people here will try our best to bring more value for our friends and partners from all of the world, by our top class machinery and service, all the time!
