Spiral Washer
- QINGDAO/SHANGHAI/TIANJIN
- T/T
You May Like
Product Details
| Condition | New | Motor Type | AC Motor | |
| Power(W) | 7.5kw | Capacity(t/h) | 40-50tph | |
| Place of Origin | Henan, China | Brand Name | Yufeng | |
| Model Number | XL610 | Weight | 3.8t | |
| Certification | ISO&CE | Warranty | 2 years | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High quality sand washer
screw sand washer can wash and separate the soil and foreign material in the sand. Its novel structure, adjustable overflow dam baffle and reliable arrangement can make sure the result of wash.
Spiral Sand Washer is widely used to wash, classify, rid impurities, and choose the coarse from the fine in the industries of highway, hydropower, construction, and so on. It is better to wash construction and road sandstone.
Characteristics and advantages of Spiral Sand Washer:
XL series spiral sand washer machine cost screw has the characteristics of reasonable structure, convenient maintenance, high output, low power consumption, and high degree of cleanness. Its novel sealed structure, totally-enclosed oil-bath transmission system, and adjustable overflow slice ensure the characteristics of high efficiency, durability, cleanness, and good dehydrating effect, and reliable product size.
Technical Parameter:
| Model | XL508 | XL610 | XL762 | XL915 | 2XL915 | XL1115 | 2XL1115 |
| Screw Diameter(mm) | 508 | 610 | 762 | 915 | 915 | 1115 | 1115 |
| Length of Tub (mm) | 6705 | 7225 | 7620 | 7585 | 7585 | 9782 | 9782 |
| Max Feed Size (mm) | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 |
| Capacity (t/h) | 20 | 40-50 | 50-75 | 100 | 200 | 175 | 350 |
| Speed Of Screw (r/min) | 38 | 32 | 26 | 21 | 21 | 17 | 17 |
| Motor Power (kw) | 5.5 | 7.5 | 11 | 11 | 2×11 | 15 | 2×15 |
| Water Consumption (t/h) | 6-60 | 6-63 | 9-63 | 10-80 | 20-160 | 20-150 | 40-300 |
| Overall Dimensions(L×W×H)(mm) | 8000× 2343×1430 | 8000× 2050×1400 | 8545× 2650×3862 | 8500× 2810×3600 | 8420× 3765×3960 | 10970× 3945×4720 | 10970× 5250×4720 |
| Weight (t) | 2.67 | 3.80 | 5.23 | 6.27 | 11.11 | 10.18 | 17.94 |
Spiral washer for sale
...
