Professional Supply for 200-300 Tpd Rotary Dryer

FOB Price

US$ 7,500 - 95,000 / Set

1 Set(Min. Order)

Port Shanghai Tianjin Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary Drying Equipment
Place of Origin	Henan, China	Brand Name	GMG
Model Number	Rotary Dryer	Voltage	380-400v
Power(W)	3-75 kw	Dimension(LWH)	as per specifications
Weight	2.9-104.9	Certification	CE,ISO
Warranty	one year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

200-300 tpd Rotary drum Dryer
1. High efficient; 2,energy -saving;3. easy operation

Introduction of Rotary Dryer

Rotary dryer is also called rotary rum dryer, which is widely used in building materials, metallurgy, chemical industries and cement industry to dry the stuff such as limestone, coal powder, slag and clay. It mainly consists of revolution body, stuff-raising plate, transmission device, support device and sealing ring. It has the advantages of reasonable structure, fine facture, high production, low energy consumption and convenient operation compared with other companies. We guarantee the quality and pay attention to the reputation.

Application & Composition:

The indirect heat transfer dryer made by our company can be used in building materials, metallurgy, chemical industry, cement plant for drying of limestone slag, coal powder, slag, clay stone. This dryer is formed of rotary body, lifting blade, driving device, supporting device and sealing ring.

Rotary Dryer Advantages:

The dryer has advantages of reasonable structure, high efficiency, low energy consumption and convenient transportation.

Performance Characteristics of Rotary Dryer:This series drier is used for drying materials with humidity or granularity in

the industries of mineral dressing, building material, metallurgy and chemical. Rotating dryer can be used for drying many kinds of materials and with convenient and reliable operation; therefore, it has been widely used.

Technical data of Rotary Dryer :

Model(mm)	Indiclination(%)	Rotation speed (r/min)	Input tempreture (oC)	Motor Power(kw)	Output(t/h)	Weight(t)
Φ600*6000	3-5	3-8	≤700	3	0.5-1.5	2.9
Φ800*8000	3-5	3-8	≤700	4	0.8-2.0	3.5
Φ800*10000	3-5	3-8	≤700	4	0.8-2.5	4.5
Φ1000*10000	3-5	3-8	≤700	5.5	1.0-3.5	5.6
Φ1200*10000	3-5	3-8	≤700	7.5	1.8-5	14.5
Φ1200*12000	3-5	3-8	≤700	11	2-6	14.8
Φ1500*12000	3-5	2-6	≤800	15	3.5-9	17.8
Φ1800*12000	3-5	2-6	≤800	18	5-12	25
Φ2200*12000	3-5	1.5-6	≤800	18.5	6-15	33
Φ2200*18000	3-5	1.5-6	≤800	22	10-18	53.8
Φ2200*20000	3-5	1.5-6	≤800	30	12-20	56
Φ2400*20000	3-5	1.5-5	≤800	37	18-30	60
Φ2800*15000	3-5	1.5-5	≤800	40	20-35	72.5
Φ2800*18000	3-5	1.5-5	≤800	40	25-35	75
Φ3000*20000	3-5	1.5-5	≤800	55	28-40	78
Φ3000*25000	3-5	1.5-5	≤800	75	32-45	104.9
