Stainless Steel Bucket SS304 Stainless Steel Elevator Bucket Carbonate Buckets Deep Bottom Elevator Bucket

   FEATURES:
• Bottomless elevator Buckets for agricultural use.
• An assembly of several bottomless elevator buckets and one bucket with bottom is installed at a close spacing on the belt. This will allow materials to be conveyed continuously allowing larger capacity. Capacity will increase 1.5~2 times by using bottomless elevator buckets. Bottomless elevator buckets can be used at higher discharge speed.
• Ideal for handling grains, feeds, fertilizers, seeds, salt and chemicals, etc.

  1.International standard packing.

  2.Large stock  of best seller production,prompt delivery

  3.Accepept special packing requirment.

Using Recommendations
• Minimum bucket spacing: Buckets spacing in one group= “C” +1mm; Bucket spacing between the groups= Bucket Projection“B” Bucket Depth “C” +25mm.
• For engineering purposes, we recommend using “L” for usable capacity.
• Mounting holes can be customized on request Using Recommendations
• Minimum bucket spacing: Buckets spacing in one group= “C” +1mm; Bucket spacing between the groups= Bucket Projection“B” Bucket Depth “C” +25mm.
• For engineering purposes, we recommend using “L” for usable capacity.
• Mounting holes can be customized on request

Zhengzhou Reafine Commerce is one of the largest manufacturers of flour ,grain and oil machinery components in China. It is a qualified enterprise, meeting FDA specification and ISO9001 standard.

We possess advanced production facilities and professionally produces all kinds of flour milling components, including Warehouse building equipment,Steel silo production machines sieve cleaner,filter mesh,nylon mesh,elevator bucket,acrylic tube,Polyester flour bolting cloth, polyester screen printing mesh ,some other stainless steel mesh for printing and filtering. Our products are widely applied in high-density printed circuit boards,CDs,ceramics, printing of T-shirt textiles, and advertisement signpost making etc..They also serve as filter in aerospace, petrifaction and other high technology regime
