PRODUCT FEATURE

1. In order to meet the requirements to use all kinds of colored sheet and materials (high and low strength sheet), our company improves the design of the forming press and adds a herringbone roller between wave crests of profile, which makes pressed sheet flat, beautiful appearance and increase the strength of the flat sheet.

2. All the rollers are forged from the high quality steel and are processed intensely through high frequency hardening and quenching and tempering. The surfaces of the rollers are plated with hard chromium. The rollers are smooth and wear proof.
The computer controls the length and the measurement, which is reliable and laborsaving.

1. Number of forming groups: 18 groups of the top

2. The machine material: welding comprise of 300 double T-steel

3. The wallboard: processing compose of 20mm steel plate

4. The mold: The mold is made of 45#steel, processed after rough turning, finish turning, finish grinding, hard chrome

plating to ensure that the mold no deformation, glabrous, wearable and accurate.

5. The shaft: The shaft is made of 45#steel, diameter of 72mm, finish turning, finish grinding after heat treatment,

quenching and high temperature tempering.

6. The bearing: Harbin type 6208

7. The roll material: 0.3-0.5mm color steel sheet, galvanized steel sheet, aluminium sheet, expansion material 1000mm,

ejection of compact effective area is 820

8. Motor:4kw * 21sets (380v)

9. Transmission: 1.0 inch chain

10. Discharge rack: 1 set

11. Machine feature: PLC NC frequency electrical boxes, touch screen`s display, the encoder counting,

the length and quantity of the material is controllable, accuracy with in 1.0mm, automatic hydraulic cut.

12. Machine Length: 7m * 1.5 m * 1.5 m

13. Machine Weight: 3.8tons

14. Production time: 30 days

15. One year warranty
