220V,1-phase,50HZ HZ-15 Concrete Core Drill (CE)
- NINGBO
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | wengong | |
| Model Number | HZ-15Concrete core drill | After-sales Service Provided | Overseas third-party support available |
Product Description
HZ-15 Concrete core drill
Diamond core drill (it is also called Concrete core drill) is a new tool drilling on reinforced concrete, bricks and fire-resistant material. It is widely used on kinds of projects concerning city construction, fitment, gas, central heating, water supply, electricity supply, aeration pipes and terrene sampling.
Technical parameter
| Model | Max bit dia | Max bit depth | power motor | Voltage | Outer dimension |
| HZ-15 | 150mm | 400mm | 2.5KW | 220v | 470×235×880mm |
| HZ-15A | 150mm | 700mm | 2.5KW | 220v | 550×300×110mm |
| HZ-15B | 150mm | 400mm | 2.5KW | 220v | 470×280×880mm |
| HZ-18 | 180mm | 400mm | 3.5KW | 220v | 470×235×880mm |
Triplex protect function
1.inserting clutch apparatus protection
2.overload protection
3.switch protection
1. Drill bit specification
Inner diameter of drill bit (mm) | Out diameter of drill bit (mm) | Drill bit length (mm) |
φ28.5 | φ37.5 | 400/700 |
φ43 | φ52 | 400/700 |
φ50 | φ60 | 400/700 |
φ55 | φ64 | 400/700 |
φ70 | φ79.5 | 400/700 |
φ75 | φ84.5 | 400/700 |
φ83.5 | φ92.5 | 400/700 |
φ100 | φ110 | 400/700 |
φ108 | φ118 | 400/700 |
φ110 | φ120 | 400/700 |
φ150 | φ160 | 400/700 |
φ190.5 | φ200 | 400/700 |
2. Details of HZ-20 concrete coring driller
3. Packing
