Home > Products > Driller machines > KHYD40DLA Electric Rock Drill
KHYD40DLA Electric Rock Drill
- shanhai ningbo
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | wengong, wengong | |
| Model Number | KHYD40DLA, KHYD40DLA | After-sales Service Provided | Overseas third-party support available |
Product Description
Specifications
Electric rock drill1.driller can drill rock, mine, soil
2.rock deep:80m, level holes size:90mm
3.drilling with high speed
KHYD40DLA Electric rock drill
1.Electric rock drill is used for drilling burst mine hole in rock.
2. It is widely used in the mine shaft excavation, road construction, water conservancy construction, metallurgy mining, rock engineering, quarry operation, basic engineering drilling reinforcement construction process.
3.The explosion-proof electric rock drill is used for drilling water injection hole, on coal seam, exploring water holes and discharging gas, also can be used for soft rock tunnel excavation.
4.Above mentioned models can do wet type and dry type work (equipped with twist drill rod). Drills holes horizontally forward or tilt up, only need to control the handwheel, the drill will track forward and backward automatically on the railway.
Technical parameter
Model | KHYD40dIA | KHYD75dIA | KHYD140dIAB | KHYD155dIAB |
Output power (kw) | 2 | 3 | 5.5 | 7.5 |
Spindle speed (r/min) | 240 | 320 | 240 | 240 |
Drilling speed (mm/min) | 280 | 320 | 280/470 | 280/470 |
Drilling diameter(mm) | 42( rock) 45-60(mine) | 42(rock) 45-80(mine) | 42-80(rock) 80-100(mine) | 42-80(rock) 80-120(mine) |
Drilling depth(m) | 5m( rock) 20-60m(mine) | 8m(rock) 30-80m(mine) | 10m(rock) 30-80m(mine) | 15m(rock) 40-100m(mine) |
Main weight (kg) | 42 | 85 | 140 | 155 |
Dimensions (mm) | 650×360×300 | 720×378×436 | 1080×460×540 | 1080×460×540 |
1. Electric rock drill can do horizontal drilling and leaning drill less than 45 angles.
2. Electric rock drill have been worked for 5years in CEBU, Philippines.
