High Precision Liquid and Powder Level Indicator NL30
US$ 20 - 100
/ Set
5 Sets(Min. Order)
- qingdao shanghai tainjin etc
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | sz | |
| Model Number | NL |
Product Description
Specifications
High precision liquid and powder level indicator1.light solid material ,powder material
pact structure
liquid and powder level indicator
Introduction:
NL Series liquid and powder level indicator is used for solid materials. It has fine sealing performance. The part connected with materials are stainless .It is widely used on chemical, plastic ,cement, pharmacy, feed and food industries.
Model:
NL10/30/31/33/34/35/36
Feature:
- American small hopper special technology, Supported by three gears to make it run reliably.
- Patent technology to avoid dust efficiently.
- Torsion is stable and reliable and can be adjusted.
- When the blade are overload, the clutch can separate automatically to protect the motor.
- Machine and motor are separated , so it is easy to maintain.
- Its IP Grade is 65, can use outside.
- Special blade can used on low density material.
Technical parameter
-
Name
liquid and powder level indicator
Model
NL30
Installation method
3/4 screw thread
Shaft length(mm)
90mm
Working temperature
-10~+80°C
Voltage
220VAC/110VAC/24VAC/24VDC
IP Grade
65
Blade Rotating Speed
1RPM
Material
Connector and paddle – Stainless steel
Blade material
SUS304
Weight
2KG
Installation type:
Dimension:
Blade type:
After-sale Service:
- Technical support online service provided.
- Technical files service provided.
- On-site training service provided.
- Spare parts replacement and repair service provided
Contact Us
- Taian Shizhe Trading Company Limited
- Contact nameDaniel Liu Chat Now
- Phone0086-150-66742604
- AddressRm. 1002, Tianyuan Commercial Mansion, Changcheng Road
