Small/ Mini Screw Conveyor for Cement Silo Industry for Powder
- Qingdao port
- T/T
You May Like
-
Flexible Screw Conveyor(diameter 168mm*length 10m) for Cement or Grain
-
DTII Type Level Belt Conveyor
-
LSY Concrete Screw Conveyor
-
650mm/800mm Corrugated Rubber Conveyor Belt
-
Manufacturer Supply Cement Screw Conveyor of Flexible Type for Sale
-
Carbon Steel Material Tubule Type Screw Conveyor With the Greatest Wear Resistance
Product Details
| Condition | New | Type | Screw Conveyor | |
| Material | Other, Carbon steel | Material Feature | Heat Resistant | |
| Structure | Conveyor System | Place of Origin | Shandong, China | |
| Brand Name | SHIZHE | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Small/ Mini screw conveyor for cement silo industry for powder1.Mint Condition,
2.Wear-resisting,
3.Simple Opeation,
Small/ Mini screw conveyor for cement silo industry for powder
We have successfully develop and put into batch production for Non-greasy lubricate screw conveyor.
1. Adopt non-greasy bearing, reliable in using and we guarantee 1.5years.
2. Avoid trouble of oil injecting and save grease.
3. Simple in structure and easy for maintenance.
Work functional picture
Specification:
Diameter of outer pipe D | Diameter of Inlet flange | Height of Inlet | Height of outlet | ||||||
A | B | C | 0-20° | >20-40° | >40-50° | 0-20° | >20-40° | >40-50° | |
H1 | H1 | H1 | H2 | H2 | H2 | ||||
140 | 200 | 250 | 280 | 400 | 450 | 500 | 250 | 300 | 350 |
168 | 200 | 250 | 280 | 400 | 450 | 500 | 250 | 300 | 350 |
219 | 300 | 350 | 380 | 500 | 550 | 600 | 300 | 400 | 450 |
273 | 300 | 350 | 380 | 500 | 600 | 700 | 350 | 450 | 500 |
323 | 300 | 350 | 380 | 550 | 700 | 800 | 400 | 500 | 600 |
407 | 470 | 470 | 530 | 750 | 900 | 1000 | 450 | 600 | 700 |
Characteristics
1. Adopt high-quality steel pipe with good integral rigidity.
2. Adopt double-pitch paddles, which decrease the compression degree of material when being transported.
3. Adopt high-quality reduction gear box with heavy-duty design, large torque and low noise.
4. Adopt optional universal ball joint, which facilitates installation, adjustment and steering.
5. Equipped with high-quality middle-hoisting bearing and tail bearing.
6. Sufficient spare parts with complete specification.
7. Large stock for common diameter of 165,219,273, 323 and 407, and dimension & angle can be customized according to your requirement.
8. Assembled by standard parts and components, which makes it convenient for transportation.
9. Adopt once-forming spiral double pitch paddles
Details:
Diameter 168mm | |||
Length (m) | reducer | speed ratio | motor power (kw) |
3 | SD1500 | 5/28 | 4 |
4 | SD1500 | 5/28 | 4 |
5 | SD1500 | 5/28 | 4 |
6 | SD1500 | 5/28 | 5.5 |
7 | SD1500 | 5/28 | 5.5 |
8 | SD1500 | 5/28 | 5.5 |
9 | SD1500 | 5/28 | 5.5 |
10 | SD1500 | 5/28 | 7.5 |
11 | SD1500 | 5/28 | 7.5 |
12 | SD1500 | 5/28 | 7.5 |
13 | SD1500 | 5/28 | 7.5 |
14 | SD1500 | 5/28 | 7.5 |
Diameter 219mm | |||
Length (m) | reducer | speed ratio | motor power (kw) |
3 | SD1500 | 5/28 | 4 |
4 | SD1500 | 5/38 | 5.5 |
5 | SD1500 | 5/38 | 5.5 |
6 | SD1500 | 5/38 | 7.5 |
7 | SD1500 | 5/38 | 7.5 |
8 | SD1500 | 5/38 | 7.5 |
9 | SD1500 | 5/42 | 11 |
10 | SD1500 | 5/42 | 11 |
11 | SD1500 | 5/42 | 11 |
12 | SD1500 | 5/42 | 11 |
13 | SD1500 | 5/42 | 15 |
14 | SD1500 | 5/42 | 15 |
Diameter 273mm | |||
Length (m) | reducer | speed ratio | motor power (kw) |
3 | SD2000 | 7/38 | 5.5 |
4 | SD2000 | 7/38 | 7.5 |
5 | SD2000 | 7/38 | 7.5 |
6 | SD2000 | 7/42 | 11 |
7 | SD2000 | 7/42 | 11 |
8 | SD2000 | 7/42 | 11 |
9 | SD2000 | 7/42 | 15 |
10 | SD2000 | 7/42 | 15 |
11 | SD3000 | 7/42 | 15 |
12 | SD3000 | 7/42 | 15 |
13 | SD3000 | 7/48 | 18.5 |
14 | SD3000 | 7/48 | 18.5 |
Diameter 323mm | |||
Length(m) | reducer | speed ratio | motor power (kw) |
3 | SD2000 | 7/38 | 7.5 |
4 | SD2000 | 7/42 | 11 |
5 | SD2000 | 7/42 | 11 |
6 | SD3000 | 10/42 | 15 |
7 | SD3000 | 10/42 | 15 |
8 | SD3000 | 10/48 | 18.5 |
9 | SD3000 | 10/48 | 18.5 |
10 | SD3000 | 10/48 | 18.5 |
11 | SD3000 | 10/48 | 22 |
12 | SD3000 | 10/48 | 22 |
13 | SD3000 | 10/48 | 22 |
14 | SD3000 | 10/48 | 22 |

- Technical support online service provided.
- Technical files service provided.
- On-site training service provided.
- Spare parts replacement and repair service provided
