Dust Collector Cyclon,dust Collector,magnetic Dust Collector for Sale
- QINGDAO
- T/T
You May Like
-
Flour Dust Collector,stone Dust Collector Machine,sandblasting Dust Collector for Sale
-
Saw Dust Collector,nail Dust Collector,centrifugal Dust Collector for Sale
-
Industrial Dust Collector,jet Dust Collector 2016 New Design
-
Bag House Dust Collector,cartridge Dust Collector,wood Dust Collector for Sale
-
Dust Collection,dust Collector
-
Portable Dust Collector,fan Filter 2016 New Design
Product Details
| Condition | New | Type | Other, dust catcher | |
| Efficiency | 99.9% | Minimum Particle Size | 40um | |
| Place of Origin | Shandong, China | Brand Name | DOM | |
| Model Number | SV | Dimension(L*W*H) | Diameter 800mm | |
| Weight | 110kg | Certification | CE | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
TechnicalFeatures • Maintenance height = 1,080mm • High filtration efficiency low dust emission level • Maintenance easy • No tools required for filtering element removal. Complete replacement of filter media by only one person within a few minutes |
construction drawing
Technical data
| Product model | SV-V2 | SV-J1 |
| Filtration area | 24m2 | 24m2 |
| Wind capacity | 1500m3/h | 1500m3/h |
| Filtration efficiency | 99.9% | 99.9% |
| Noise | under 85dB | under 75dB |
| Cleaning method | Vibration cleaning intermittent working way | Pulse air-jet cleaning continuous working |
| Compressed air | - | 4-6 bar |
| Control panel power | 380V/50Hz | 220V/50Hz |
| Structure | Stainless steel | Stainless steel |
| Connecting way | Flange connection | Flange connection |
1.SV-V2: Vibrating Type
| Vibrating type is used on top silo.Dust separated from the air flow by filter elements drops back into the silo after vibration. |
2.SV-J2:Air-Jet Type
Dust separated from the air flow by filter elements drops back into the silo after an integrated automatic reverse air jet cleaning system inside the weather protection cover has removed it from the filter elements. The air jet cleaning system is integrated in the hinged weather protection cover. |
3. Dust collector with blower and dust collector hopper:
| Dust separated from the air flow by filter elements drops back into the dust collector hopper after an integrated automatic reverse air jet cleaning system inside the weather protection cover has removed it from the filter elements. The fan system provide negative pressure which help to keep air filtration more efficient. |
4.Filter inside
Filter inside is folded PET filter.
Thickness of the filter is only 0.2mm,easy to clean and have long working life.
using
paking&shipping
company information
SDDOM Machinery is the most innovative concrete machinery company. Mobile and Stationary China supplier road construction equipments concrete batching plant price construction companies indonesia, Bolted and Horizontal Silo, Planetary and Twin Shafts mixer and other more than 10 kinds of products are certificated by CE or get patent. Every step of Every equipment will be signed and checked from design, drawing, production, test to delivery. All the processing steps are meeting the requirements of Europe CE. More and more clients around the world come to visit our factory every month. Australia, Sweden, Denmark, France, Saudi Arabia, Kuwait, Indonesia, South Africa, USA, Brazil. Welcome friends from all over the world to visit us! Powerful Overseas Engineers Service team will provide you with professional technical support. |
