Home > Products > Mobile concrete batching plant > 50m3 Mobile Concrete Plant Used Mobile Concrete Batching Plants
50m3 Mobile Concrete Plant Used Mobile Concrete Batching Plants
- Qingdao
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Shandong, China | Brand Name | Jianling | |
| Model Number | YHZS50 | Power(W) | 110kw | |
| Weight | 17.8t | Certification | TUV ISO | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
50m3 mobile concrete plant used mobile concrete batching plants
1.ISO TUV after service
2.Automatic operation by PLC+IPC
3.Different Types
*We can customize according to your requirements, welcome to enquire---Concrete Mixer, Batching Machine, Screw Conveyor, Cement Silo and Concrete batching Plant.
50m3 mobile concrete plant:
Capacity | 60m3/h | |
Mixer | JS1000 | |
Compact concrete output | 1m3 | |
Aggregate size | <=60mm | |
Aggregate Bins | 4x4.5m3 each | |
Accuracy | Aggregate | 0~3000kg ≤±2% electronic scale |
| Cement | 0~600kg, ≤±1%, electronic scale |
| Water | 0~300kg, ≤±1%, electronic scale |
| Admixture | 15~30kg, ≤±1%, electronic scale |
Discharge clearance | 2.80 meters | |
Trail speed | 15km/h | |
Occupy space | 22.2×2.4 m2 | |
Air supplying press | 0.6MPa | |
Control form | automatic/ manual | |
Total power | 60kw(excluding screw) | |
Total weight | 30 MT (excluding screw conveyor and silo) | |
Concrete Batching Plant / Concrete Mixing Plant Features:
1. The concrete batching plant / Concrete Mixing Plant is a large-scale concrete mixing equipment, combining material storage, measurement and mixing, with high output.
The equipment, which adopts forced mixer with double horizontal shafts as its matching principal machine with 3.8m concrete unloading height, can mix all kinds of concrete, especially hard concrete
2. Applicable for projects of architectures, water and electricity, highways, ports, docks and bridges in medium scale as well as large-and-medium scale preformed unit plants and concrete manufacturing plants.
3. Microcomputer control and electronic scale weighing guarantee high measuring accuracy and small error.
4. Functions include screen display, batching storage, automatic gap compensation and manual system which makes manual and automatic control available in mixing process.
In addition, the equipment is equipped with printing system and can be installed with monitoring system according to user demand to realize concentrated control and integral management of the entire equipment.
Stationary Concrete Batching Plant Main Technical Parameters:
Model | HZS25 | HZS40 | HZS50 | HZS75 | |
Theoretical Output Rate (m3/h) | 25 | 40 | 50 | 75 | |
Mixer | Model | JS500 | JS750 | JS1000 | JS1500 |
Power(kw) | 18.5 | 30 | 18.5×2 | 30×2 | |
Discharging Capacity | 0.5 | 0.75 | 1 | 1.5 | |
Production Cycle(s) | 72 | 72 | 72 | 72 | |
Capacity of Aggregate Storage Bin m3 | 3×4 | 3×4.5 | 3×8 | 3×8 | |
Measuring Accuracy % | Aggregate | ±2 | ±2 | ±2 | ±2 |
Cement | ±1 | ±1 | ±1 | ±1 | |
Water | ±1 | ±1 | ±1 | ±1 | |
Additive | ±1 | ±1 | ±1 | ±1 | |
Coal Ash | ±1 | ±1 | ±1 | ±1 | |
Matching Cement Bin | SNC50 | SNC100 | SNC100 | SNC100 | |
Matching Cement Screw Conveyor | LSJ40 | LSJ40 | LSJ40 | LSJ80 | |
Matching Coal Ash | SNC50 | SNC100 | SNC100 | SNC100 | |
Matching Coal Ash Screw Conveyor | LSJ40 | LSJ40 | LSJ40 | LSJ40 | |
Discharge Height( m) | 3.8 | 3.8 | 3.8 | 3.8 | |
Mobile Concrete Plant:
mobile concrete batching plants
50m3 mobile concrete plant used mobile concrete batching plants
50m3 mobile concrete plant used mobile concrete batching plants
We have cooprerate with many big companys since 1998, such as
China Communications Construction Group,
China Railway Construction Group,
China Railway Two Bureau Group of Beijing Tianjin high-speed project,
Gezhou Dam Group,
Shandong Gangji Construction Group Commercial Concrete Co.,Ltd,
China Railway Tunnel Group,
Tangshan Highway Construction Corporation,
Zibo Construction Group,
Anhui Construction Engineering Group Co.,Ltd and so on.
Gangji Concrete: HLS180 Concrete Batching Plant
HZS Concrete Batching Plant
HZS50 Concrete Batching Plant
Tangshan Road Construction: HZS75 Concrete batching plant
HZS120 Concrete Batching Plant
