HZS75 Factory Suppy Cheap Ready-mixed Concrete Batching Plant
- Qingdao
 - T/T Credit Card

You May Like
-


HZS40 Factory Supply Low Price Cement Batching Plant
 -


HZS25 t Concrete Mixer Plant for Sale With Famous Brand
 -


YHZS50 Factory Supply Mobile Concrete Batch Plant
 -


YHZS50 Factory Supply Mobile Concrete Ready Mix Plant
 -


YHZS50 Factory Supply Mobile Concrete Batcher Plant
 -


Sand, Aggregate Batching Machine for the Concrete Making System Used

Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Shandong, China | Brand Name | Jianling | |
| Model Number | HZS75 | Power(W) | 150kw | |
| Dimension(L*W*H) | ready-mixed concrete batching plant | Weight | 20t | |
| Certification | TUV ISO | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HZS75 Factory Suppy Cheap Ready-mixed Concrete
Batching Plant
*We can customize according to your requirements, welcome to enquire---
Concrete Mixer, Concrete Screw Conveyor, Batching Machine, Cement
Silo and Concrete Batching Plant.
Concrete batching plant / Concrete mixing plant Features:
The equipment, which adopts forced mixer with double horizontal shafts as its matching
principal machine with 3.8m concrete unloading height, can mix all kinds of concrete,
especially hard concrete
2. Applicable for projects of architectures, water and electricity, highways, ports, docks
and bridges in medium scale as well as large-and-medium scale preformed unit plants
and concrete manufacturing plants.
3. Computer control and electronic scale weighing guarantee high measuring accuracy
and small error.
4. Functions include screen display, batching storage, automatic gap compensation and
manual system which makes manual and automatic control available in mixing process.
In addition, the equipment is equipped with printing system and can be installed with m-
onitoring system according to user demand to realize concentrated control and integral
management of the entire equipment.
Main Technical Parameters:
Model  | HZS25  | HZS40  | HZS50  | HZS75  | |
Theoretical Output Rate (m3/h)  | 25  | 40  | 50  | 75  | |
Mixer  | Model  | JS500  | JS750  | JS1000  | JS1500  |
Power(kw)  | 18.5  | 30  | 18.5×2  | 30×2  | |
Discharging Capacity  | 0.5  | 0.75  | 1  | 1.5  | |
Production Cycle(s)  | 72  | 72  | 72  | 72  | |
Capacity of Aggregate Storage Bin m3  | 3×4  | 3×4.5  | 3×8  | 3×8  | |
Measuring Accuracy %  | Aggregate  | ±2  | ±2  | ±2  | ±2  |
Cement  | ±1  | ±1  | ±1  | ±1  | |
Water  | ±1  | ±1  | ±1  | ±1  | |
Additive  | ±1  | ±1  | ±1  | ±1  | |
Coal Ash  | ±1  | ±1  | ±1  | ±1  | |
Matching Cement Bin  | SNC50  | SNC100  | SNC100  | SNC100  | |
Matching Cement Screw Conveyor  | LSJ40  | LSJ40  | LSJ40  | LSJ80  | |
Matching Coal Ash  | SNC50  | SNC100  | SNC100  | SNC100  | |
Matching Coal Ash Screw Conveyor  | LSJ40  | LSJ40  | LSJ40  | LSJ40  | |
Discharge Height( m)  | 3.8  | 3.8  | 3.8  | 3.8  | |

After-sale service:
1.Warranty:1 year
2.Eengineer is available to service abroad.
3.Techincal assistance is avaible in 24 hours.
