HLS120 Factory Suppy 2015 Cement Concrete Mixing Plant
- Qingdao
- T/T Credit Card
You May Like
-
HLS90 Factory Supply Concrete Mixing Plant With Good Service
-
HLS60 Factory Supply Ready Mixed Concrete Mixing Plant
-
100% Qualified HZS60, Ready Mixed Concrete Batching Plant, Concrete Mixer, Precast Concrete Mixing Plant
-
Fewer Quality Concrete Mixing Plant HLS60 / Concrete Mixstaton HLS60
-
Continuous Concrete Admixture Batching Station HLS60
-
Continuous Concrete Batching Station HLS90
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Shandong, China | Brand Name | Jianling | |
| Model Number | HLS120 | Power(W) | 178kw/mixing power 2X55kw | |
| Dimension(L*W*H) | cement concrete mixing station | Weight | 70t | |
| Certification | TUV ISO | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HLS120 Factory Suppy 2015 Cement
Concrete Mixing Plant
Features
1. HLS series second-order concrete batching plant adopts biaxial horizontal double
-shaft compulsory concrete mixer. with even mixing quality.
2.Lump-sum aggregate equipped with the same capacity of mixer, the productivity
was 15% -30%higher than the mixing plant.
3.Aggregate, water ,admixtures weighing, control ,signal conversion device adopts
imported components, high precision sensor, automatic control of microcomputer,
each weighing or cumulative weighing, weighing precision and stable performance.
4. The complete machine is under computer control, making both automatic control
and manual operation available.
5. The tower appearance looks orderly and magnificent, with main body closed with
insulation board or single-layer color coated sheet; the tower inside is clean and enjoys
good environment-friendly performance.
Main Technical Parameters
Model | HLS60 | HLS90 | HLS120 | HLS180 |
Productivity (m3/h) | 60 | 80 | 100 | 150 |
Main machine | MAO1000 | MAO1500 | MAO2000 | MAO3000 |
Max value of aggregate scale(kg) | 3000 | 4500 | 6000 | 9000 |
Max value of cement scale(kg) | 600 | 1000 | 1200 | 1800 |
Max value of fly ash scale(kg) | 300 | 500 | 500 | 800 |
Max value of water scale(kg) | 300 | 500 | 600 | 800 |
Max value of fluid additive scale(kg) | 30 | 30 | 50 | 50 |
Mixing power (kw) | 2*18.5 | 2*30 | 2*37 | 2*55 |
Total power (kw) | 92 | 108 | 127 | 178 |
Discharge height (m) | 3.8 | 3.8 | 3.8 | 3.8 |
Aggregate weighing precision(%) | +/_2 | +/_2 | +/_2 | +/_2 |
Cement weighing precision(%) | +/_1 | +/_1 | +/_1 | +/_1 |
Water weighing precision(%) | +/_1 | +/_1 | +/_1 | +/_1 |
Additive weighing precision(%) | +/_1 | +/_1 | +/_1 | +/_1 |
After-sale service:
1.Warranty:1 year
2.Eengineer is available to service abroad.
3.Techincal assistance is avaible in 24 hours.
Certificates
Some projects we took part in
