Home > Products > HLS Concrete Mixing Plant > HLS90 Factory Supply Concrete Ready Mix Plant With Good Service
HLS90 Factory Supply Concrete Ready Mix Plant With Good Service
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Shandong, China | Brand Name | Jianling | |
| Model Number | HLS90 | Power(W) | 152kw/mixing power 2X30kw | |
| Dimension(L*W*H) | dry concrete mixing plant | Weight | 35t | |
| Certification | TUV ISO | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HLS90 Factory Supply Concrete Ready Mix Plant
With Good Service
Features:
1. HLS series second-order concrete batching plant adopts biaxial horizontal double-
shaft compulsory concrete mixer. with even mixing quality.
2.Lump-sum aggregate equipped with the same capacity of mixer, the productivity
was 15% -30%higher than the mixing plant.
3.Aggregate, water ,admixtures weighing, control ,signal conversion device adopts
imported components, high precision sensor, automatic control of microcomputer,
each weighing or cumulative weighing, weighing precision and stable performance.
4. The complete machine is under computer control, making both automatic control
and manual operation available.
5. The tower appearance looks orderly and magnificent, with main body closed with
insulation board or single-layer color coated sheet; the tower inside is clean and enjoys
good environment-friendly performance.
Main Technical Parameters:
Model | HLS60 | HLS90 | HLS120 | HLS180 |
Productivity (m3/h) | 60 | 80 | 100 | 150 |
Main machine | MAO1000 | MAO1500 | MAO2000 | MAO3000 |
Max value of aggregate scale(kg) | 3000 | 4500 | 6000 | 9000 |
Max value of cement scale(kg) | 600 | 1000 | 1200 | 1800 |
Max value of fly ash scale(kg) | 300 | 500 | 500 | 800 |
Max value of water scale(kg) | 300 | 500 | 600 | 800 |
Max value of fluid additive scale(kg) | 30 | 30 | 50 | 50 |
Mixing power (kw) | 2*18.5 | 2*30 | 2*37 | 2*55 |
Total power (kw) | 122 | 152 | 195 | 283 |
Discharge height (m) | 3.8 | 3.8 | 4.2 | 4.2 |
Aggregate weighing precision(%) | +/_2 | +/_2 | +/_2 | +/_2 |
Cement weighing precision(%) | +/_1 | +/_1 | +/_1 | +/_1 |
Water weighing precision(%) | +/_1 | +/_1 | +/_1 | +/_1 |
Additive weighing precision(%) | +/_1 | +/_1 | +/_1 | +/_1 |
After-sale service:
1.Warranty:1 year
2.Eengineer is available to service abroad.
3.Techincal assistance is avaible in 24 hours.
Some projects we took part in
concrete make plant dry concrete mixing plant
Certificates
Contact Us
- Shandong Jianling Machinery Co., Ltd.
- Contact nameCathy cheng Chat Now
- AddressNo. 6, Industrial Middle Road, Gushan Industrial Park, Changqing Dist.
