HDPE PLASTIC MONOFILAMENT YARN EXTRUDER
- QingDao
- T/T Credit Card PayPal
You May Like
-
Plastic Extruders PP PE PET Monofilament Fiber Making Machine From Chinese Factory
-
Single-screw Screw Design PP PE PET Monofilament Extruder Machinery / Rope Roping Production Line
-
Manufacturer All Kinds of Rope Tipping Machine in China
-
Manufacturer Tipping Shoelace Cords Machine in China
-
Manufacturer Shoelace Handle Bag Rope Tipping Machine
-
Easy Operation PE Film Shrink Machine for Bottles
Product Details
| Condition | New | Application | Other | |
| Plastic Processed | PP | Screw Design | Single-screw | |
| Automatic Grade | Semi-automatic | Place of Origin | Shandong, China | |
| Brand Name | CNRM | Model Number | HDYSJ-80 | |
| Voltage | 380V | Power(W) | 130KW/80KW | |
| Dimension(L*W*H) | 23m*3m*2.5m | Weight | 12000kg | |
| Certification | CE ISO9001 BV | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HDPE PLASTIC MONOFILAMENT YARN EXTRUDER
The PP monofilament yarn extruder can produce many kinds of fiberby differernt screw and related equipments,such as HDPE and PP monofilament fiber.
The fibers can be used for the manufacturing of industry, fishing industry and civilian use, like rope ,fishing net,construction safety net, PP bad and etc.
| Flow Chart of PP monofilament extruder |
Raw material---> Extruder---> Water cooling--->Stretching--->Heating--->Stretching
---> Guide roller--->Winder
| Performance & Advantages |
* Longer life of screw & barrel
* AC Invertor & Motor which synchronizes the entire extruder
* PP & LD can be processed due to its special screw design
* Latest technology used to force the melt into the die very effectively
* Take up small area
* Simple operation
* High output capacity
* Low maintenance
Technology information details
Item | HDYSJ-70 | HDYSJ-80 | HDYSJ-90 |
Dia of Fiber | 0.13mm-0.30mm | 0.13mm-0.30mm | 0.15mm-0.3mm |
Dia of Screw | 70mm | 80mm | 90mm |
Ratio of L/D | 30 | 33 | 33 |
Rotation Speed of Screw | 20-90r/min | 20-90r/min | 20-90r/min |
Drawing Ratio | 4-10 | 4-10 | 4-10 |
Heating Mode | Electric heating | Electric heating | Electric heating |
Cooling Mode | Water Cooling | Water Cooling | Water Cooling |
Power Consumption | 100kw/65kw | 130kw/80kw | 150kw/100kw |
Max Outputcapacity | 1400kg/24h | 2000kg/24h | 3000kg/24h |
Machine Dimension(L*W*H) | 20m*3m*2.5m | 23m*3m*2.5m | 27m*3m*2.5m |
Machine Weight | 9000kg | 12000kg | 15000kg |
Product Show
Olivary Shape Winder
H Bobbin Shape Winder
Column Shape Winder
Contact Us
- Taian Haidai Rope Machinery Science Technology Co., Ltd.
- Contact nameFrank Zhang Chat Now
- Phone86-538-6578689
- AddressNo. 39, Jiuxing Street, Shengzhuang Town Industrial Zone, Taishan Dist.
