YHG Turn Brush Type Aerator Machine(ending Drive-three Tanks)

wooden package,container,
export seaworthy package

Specifications

YHG turn brush type ending drive-three tanks

USES:

BZS2 type series ending drive-three tanks used in turn brush sewage treatment plant oxidation ditch, the role is to promote oxygen filling in wastewater, sewage in the ditch circulating activated sludge precipitation, and prevent sewage and oxygen to fully mixing, complete with biochemical processes.

BZS2 by vertical motor, spiral cone-cylindrical gear reducer, main shaft and brush, end of housings, lubricating system and control cabinet composition.
Main features: BZS2 type series ending drive-three tanks in turn brush is BZS type, on the success of the second design improvement, the product has the following features:
1) the vertical motor drives special spiral cone-of cylindrical gears reduction gear, with cover an area of an area small, easy to process arrangement, motor and the liquid surface distance, and greatly reduced sewage water mist of the motor insulation performance of the influence;
2) turn brush tail bearing structure reasonable ending drive-three tanks, assembling, testing and maintenance convenient;
3) turn brush according to slow down ending drive-three tanks model type points have G, Z of two types, G as bottom mounted feet, Z axis outfit for installation type.
G type: turn brush the driving end do not set housings, reducer output shaft through the coupling and turn brush shaft connection; Replacement parts and maintenance deceleration machine, turn brush components should be a temporary support; The tailstock and reducer output shaft the coaxial tolerance of the demand is high, installation, high accuracy trouble.
Z type: turn driving end the bearing a brush, without coupling; Replacement parts and maintenance deceleration machine, turn brush parts maintain in situ; Speed reducer is easy to installation, don't need to. The machine installation precision low demand.
4) load and oxygen filling by adjusting submerged water level and design change.

Working principle: all the spindle cloth brush brush in the piece, turn in drive the drive rapidly rotating, brush of water into the air, to form water jump, fully contact with air, the air in the water, achieve rapid oxygen filling purpose. At the same time brush tablets in water has pushed flow function, let the water cycle, and constantly update the surface of the water, make active sludge is in a state of suspension.

Main technical parameters

 Craft diagram
