Home > Products > Mechanical bar screen > XWN Microfiltration Machine for Texile Waste Water Treatment
XWN Microfiltration Machine for Texile Waste Water Treatment
- Qingdao
- T/T
You May Like
-
WN Hot Sale Papermaking Wastewater Treatment Equipment
-
WL Quality Micro Filter Machine
-
WN Rotating Drum Wastewater Filtration Machine for Industrial Sewage Filter
-
Micro Drum Filtration Machine for Papermaking Wastewater Treatment
-
Microfiltration Machine,water Filter Equipment for Wastewater Treatment
-
Industry Wastewater Treatment Rotary Bar Screen
Product Details
| Place of Origin | Shandong, China | Brand Name | jinhaosanyang | |
| Model Number | XWN |
container
export standard package
Product Description
Specifications
microfiltration machine1. filter area:5-18m2
2. filter whitewater capacity: 5-380T/H
3. material: stainless
XWN Microfiltration machine for texile waste water treatment
Specifications
1Double SS filter nets
2)Be Suitable for solid-liquid separation
3)Be widely used in waste water treatment
Features
1.Self-cleaning screen waste remover is composed of main frame, driving device, tooth harrow and transmission chains.
2.Teeth with ABS, nylon 6, nylon 1010 or stainless steel material are ranked on axis to form a seal chain.
3.It pushes waste to flow into tank instead of to the top guided by rail and wheel. And brush will clean the residue on teeth.
4.It is installed at water inlet of secondary grill and other water intake units where no large particles are in water. It is also can be used for industrial and municipal sewage of industries such as paper mill, textile, leather, wine and sugar making, fishing etc.
5.Chain rotor multi teeth screen waste remover is developed on the basis of advance technology from similar products both at home and abroad. Several teeth (4-8 pcs) are uniformly placed on chains with certain space, it moves from back of grill to front so as to push waste to discharging pole along preventing board where waste can be moved by transferring device or presser.
6.It is suitable for usage at premier and secondary fence of water inlet of water intake units.
The machines adopt 15-20 micron holes to filter, a mechanical filtration. They can separate the tiny suspended material from the liquid as far as possible,
and make the solid and liquid individual completely. They are widely used in the occasions, such as paper making, textile, printing and dyeing, chemical industry, food industry. Especially for the clear water treatment, so it can be used canned cycle.
Technical datas
Model | XWN1 | XWN2 | XWN3 | XWN4 | XWN5 | XWN6 | XWN7 | XWN8 |
Filter area (m2) | 6 | 7 | 9 | 11 | 14 | 16 | 24 | 30 |
Mesh | 60-250 | 60-250 | 60-250 | 60-250 | 60-250 | 60-250 | 60-250 | 60-250 |
Water treatment (m3/h) |
50-100 |
80-150 |
100-200 |
120-240 |
150-300 |
170-350 |
240-400 |
300-500 |
Power of motor (kw) | 1.1 | 1.1 | 1.5 | 2.2 | 3 | 4 | 5.5 | 7.5 |
Filter diameter (mm) | 1000 | 1250 | 1250 | 1500 | 1500 | 1500 | 1780 | 1780 |
Filter effective length (mm) | 1500 | 1800 | 2300 | 2370 | 2870 | 3370 |
Production flow
Certificates
Contact me
Company Profile
Shandong Jinhaosanyang Environmental Protection Equipment Co., Ltd. is a new high-tech company. Our company is a prestigious, formal, large-scale and environmental protection machinery manufacturer in China, and has an absolute competitive strength in the field. Our company has 300 employees, including technical and management staff members of more than 50. Our company has the advantages of processing technology, large-scale equipment, specialized personnel, design experience, and advanced technology force. We have cooperated with environmental experts and design professors in famous universities and institutions, independently developing production sewage treatment equipment, filtration equipment, pulping equipment and boiler dedusting equipment. We are a comprehensive mechanical equipment development enterprise. Relying on existing conditions, we research and develop the internationally advanced technology. Our company has developed a variety of highly automated and reliable sewage treatment equipment. Products are sold throughout the world, such as Egypt, Vietnam, New Zealand, Finland, the Netherlands, Australia and other countries and regions. Our company has implemented a science-oriented view of development, and consistently pursuing the tenet of "credibility first, quality first, being proactive, innovative and pioneering". We have made brilliant achievement in various industrial fields. We always adhere to the principle of "equality and mutual benefit, Quality First and Reliable Reputation". By joint efforts, we hope to promote both trade and friendship to our mutual advantage. Zhucheng Jinhaosanyang Environmental Protection Equipment Co., Ltd. sincerely welcomes your visit. We hope to cooperate with international guests and friends to create the resplendence together!
