Wood Edge Banding/ Sealing Machine
- qingdao guangzhou
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | YINGWANG | Model Number | YW-WEB1 YW-WEB 2 YW-WEB 3 YW-WEB4 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
wood box, carton box
Product Description
Wood edge banding/ sealing machine
Feature of : Manual wood edge banding machine
1,Suitable for straight or curved work piece welt.
2,Hot melt adhesive coating automatic function does not have to trim fabric
glue.
3, Can be hand-held mobile or fixed welt welt machine operation.
4,A worker needed
5, Variable speed control / electronic temperature / fast heating.
Parameters for Manual wood edge banding machine
Model | YW-WEB1 | YW-WEB 2 | YW-WEB 3 | YW-WEB4 |
Side bar thickness(mm) | 0.4~3 | 0.4~3 | 0.4~3 | 0.4~3 |
Side bar Width(mm) | 10~65 | 10~65 | 10~65 | 10~65 |
Banding Speed(m/min) | 4.0 | 4.0 | 0.1~4.0 | 0.1~4 |
Consumption(W)(220V) | 855 | 855 | 855 | 855 |
Hot Melt Glue Temperature (℃) | 120~200 | 120~200 | MODE1:120~200 MODE2:80~155 | MODE1:120~200 MODE2:80~155 |
Melt Glue furnace capacity(ml) | 400 | 400 | 400 | 400 |
Weight | 8.7kg | 8.7kg | 8.8kg | 8.8kg |
Gross Weight | 11kg | 19.6kg | 11.1kg | 19.7kg |
Packing Size | 250*190*350 | 250*190*350 | 250*190*350 | 250*190*350 |
pls feel free to contact me
Company Profile
zhengzhou yingwang machinery co., ltd has 15 years of experience in production and sales. our main products are farm machine, oil machine, wood machine, food machine, and waste recycling machine. We adopt advanced production technology, produce high quality machine.and always uphold the quality first, customer-oriented principle, to win the big market of domestics and abroad. Our products have been exported to Europe, America, Asia and African and other regions. OEM service is also available. we insist on "First Quality, First Trust, and First Serice"as our business philosophy, forcuses on international and domestic markets, strives for excellence. we are sincerelly expecting to cooperate with you and win-win, warmly welcome to visit our company, let's create bright future together.
