Stainless Rustless Iron Rod Steel Bar Polishing Machine
- Qingdao Shenzhen Tianjin Shanghai Guangzhou
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | YW | |
| Model Number | YW-7 | After-sales Service Provided | Engineers available to service machinery overseas |
steel bar polishing machine is packed by wooden case
Product Description
Introductions of steel bar polishing machine :
The main features: increase the cooling system, it can be loaded grinding wheels, the wheel rotation speed can be adjusted, to control the speed of the feeding, and can satisfy the demands of different diameter workpiece grinding and polishing.
Application of steel bar polishing machine :
it is suitable for all kinds of axle, member bar, pope fittings cylindrical surface grinding and polishing; long stainless steel tube, boiler tube, high precision drawn tube, ti-alloy bars; engineering machinery hydraulic lever, automobile and motorcycle shock absorber rod, valve rod, oil field pumping polished rod; polishing and grinding of various kinds of all kinds of metal/metal bar, pipe, plastic, plastic rubber tube, textile machinery polished rod and wire rod.
Specification of steel bar polishing machine :
Model | YW-7 | YW-10 | YW-12 | YW-23 |
Max working dia.(MM) | 1-80 | 1-120 | 1-150 | 20-200 |
Max working length(MM) | 6000 | 6000 | 6000 | 6000 |
Main roll dia.(MM) | 32 | 32 | 32 | 32 |
Max wheel dia.(MM) | 300 | 300 | 300 | 300 |
Max wheel thickness(MM) | 160 | 160 | 160 | 160 |
Guide roller dia.(MM) | 230 | 230 | 260 | 260 |
Buff whell speed(r/min) | 2800 | 2800 | 2800 | 2800 |
Guide roller speed(r/min) | 0-200(adjustable) | |||
Working speed(m/min) | 0-10(adjustable) | |||
Buff wheel power(KW) | 3 | 3 | 4 | 4 |
Guide roller power(KW) | 0.4 | 0.4 | 0.8 | 0.8 |
Total power(KW) | 3.4 | 3.4 | 4.8 | 4.8 |
Total weight(KG) | 320 | 360 | 420 | 460 |
Dimension (MM) | 900*700*1200 | 1000*700*1200 | 1100*800*1200 | 1200*800*1200 |
Lighting voltage(V) | 36 | 36 | 36 | 36 |
Bar polishing machine is guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free.
a, Before sending the machine, we will test and adjust, so you can use directly when you get it.
b, Operation video & instruction will be sent to clients, to help them use the machines better.
Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will solve your problems in time. If you are caught in some problems when using our products, welcome to contact us at any time.
a, Any problems occur while using, professional advice will be offered.
b, All kinds of frequently used parts are supplied all the year round.
c, 24 hours hot line +86-18137122335
