2016 Top Class Quality High Torque Plastic Gear Motor
Negotiable
/ Piece
100 Pieces(Min. Order)
- Shenzhen
You May Like
Product Details
| Type | Other, dc gear motor | Place of Origin | Guangdong, China | |
| Brand Name | TT MOTOR | Model Number | TGP01S-A130 |
Product Description
2016 Top Class Quality high torque plastic gear motor
MODEL:TGP01S-A130
1.available reduction ratios:1/48,1/120,1/180,1/220,1/288
2.double or single shaft
3.motor size:22.5*64.2mm,micro motor
4.voltage:3.0-12.0V
5.supply soldered wires,battery box,and wheels(as pictures shown below)
6.good price and fast delivery
7.we have the motors in stock now,and samples can be sent for your test.
MODEL | VOLTAGE | NO LOAD | AT LOAD | STALL | |||||||||
OPERATING RANGE | NOMINAL | SPEED | CURRENT | SPEED | CURRENT | TORQUE | OUTPUT | TORQUE | CURRENT | ||||
V | rpm | A | rpm | A | N.m | Kg.cm | w | N.m | Kg.cm | A | |||
TGP01S-A130 | 10300-288 | 3.0-12.0 | 6 | 21 | 0.10 | 19 | 0.17 | 0.05 | 0.47 | 0.18 | 0.18 | 1.8 | 0.6 |
14175-120 | 3.0-6.0 | 4.5 | 90 | 0.20 | 72 | 0.50 | 0.03 | 0.3 | 0.38 | 0.14 | 1.4 | 1.25 | |
12215-48 | 3.0-9.0 | 3.0 | 110 | 0.12 | 85 | 0.20 | 0.01 | 0.11 | 0.13 | 0.027 | 0.27 | 0.45 | |
18100-220 | 3.0-6.0 | 3.0 | 50 | 0.25 | 34 | 0.45 | 0.07 | 0.71 | 0.52 | 0.24 | 2.4 | 1.1 | |
