wall fan

FOB Price

US$ 188 - 238 / Set

20 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Only for industrial plants, greenhouses and poultry.
Specification:1000,1250 and 1400.
Passed CE Certificated

Specification		DJF-1000		DJF-1250		DJF-1400
Fan Blades		six fan blades
Fan Diameter		1000 mm		1250 mm		1400 mm
Fan RPM		600 r/min		439 r/min		439 r/min
Fan Blades Material		1.5mm aviation aluminum alloy
Air flow (m³/h)		35000 m³/h		44000 m³/h		55800 m³/h
Total Pressure		70 pa		56 pa		60 pa
Motor Type		Three-phase motor, B3
Motor RPM		1400 r/min		1400 r/min		1400 r/min
Motor Frequency		50/60Hz		50/60Hz		50/60Hz
Insulating Grade		F		F		F
Protection Grade		IP55		IP55		IP55
Noise (db)		≤70		≤70		≤70
Power (kw)		0.75 kw		1.1 kw		1.5 kw
Voltage (v)		380		380		380
Outer Size (mm)		11001100400		13801380400		15361536400
Frame Material		1.0mm galvanized sheet
Weight (kg)		56 kgs		78 kgs		93 kgs
Weight without Motor		36 kgs		56 kgs		70 kgs
Shutters Material		galvanized sheet		galvanized sheet		galvanized sheet
Protective Net Material		galvanized wire		galvanized wire		galvanized wire
MOQ (set)		20sets		20sets		20sets
Unit Price (usd/set)		$188/set		$215/set		$238/set
Price Terms		FOB Shanghai

Terms of Payment		By T/T
Package		Packed in stretch film
Port of Loading		Shanghai, China
20 Container 20	Assembled	52 sets	28 sets		20 sets
	Unassembled	158 sets	128 sets		128 sets
Time of Delivery		Within 10 days after receiving the deposit.

Service		OEM service is available
Certification		CE
Safety Standards		EN60204-1
