Rexroth Bent Axis Hydraulic Motor A2FM250
- Ningbo, China
- T/T L/C PayPal Other Cash
- 7 days
You May Like
-
Rexroth High Speed Hydraulic Motor A2FM107 A2FM125
-
Rubber Track Undercarriage Rubber Crawler Undercarriage Rubber Tracked Undercarriage
-
Custom Built Rubber Track Undercarriage
-
1-30 Ton Custom Built Rubber Crawler Undercarriage
-
1.5 Ton Rubber Track Undercarriage
-
6 Ton Rubber Track Undercarriage (rubber Track Chassis)
Product Details
| Brand Name | cathyhsu@foxmail.com | Place of Origin | China | |
| Model Number | A2FM series | Type | Hydraulic Motors |
Product Description
Bent axis hydraulic motor manufacturer high speed hydraulic motor manufacturer
Rexroth Hydraulic Motor A2FM12, A2FM16, A2FM23, A2FM28, A2FM32, A2FM45, A2FM56, A2FM63, A2FM80, A2FM90, A2FM107, A2FM125, A2FM160, A2FM180, A2FM200, A2FM250
This fixed axial displacement piston motor A2FM, bent axis design, suitable for hydrostatic drives in open and closed circuits. It is widely applied inmobile and industrial applications .Output speed depends on the flow capacity ofthe pump and the displacement of the motor. The torque increase with thepressure differential between the high and low pressure side and with increasingdisplacement. And it can be completely interchanged with Rexroth A2FM series hydraulic motor.
Features
1. Counterbalance valve can be fitted
2. Option: Integrated pressure relief valve
3. Option: Integrated or built - on flushing and boost pressurevalves
4. Suitable for use as pump in closed circuits
5. Long - life bearings available (sizes 250 - 1000)
6. Totally interchangeable with original Rexroth A2FM series HydraulicMotor
Technical parameters
Size | A2FM | A2FM10 | A2FM12 | A2FM16 | A2FM23 | A2FM28 | A2FM32 | ||
Displacement | Vg | cm3 | 10,3 | 12 | 16 | 22,9 | 28,1 | 32 | |
Speed 1) | nmax | rpm | 8000 | 8000 | 8000 | 6300 | 6300 | 6300 | |
△p=400bar | Tmax | Nm | 65 | 76 | 100 | 144 | 178 | 204 | |
Size | A2FM | A2FM45 | A2FM56 | A2FM63 | A2FM80 | A2FM90 | A2FM107 | ||
Displacement | Vg | cm3 | 45,6 | 56,1 | 63 | 80,4 | 90 | 106,7 | |
Speed 1) | nmax | rpm | 5600 | 5000 | 5000 | 4500 | 4500 | 4000 | |
△p=400bar | Tmax | Nm | 290 | 356 | 400 | 508 | 572 | 680 | |
Size | A2FM | A2FM125 | A2FM160 | A2FM180 | A2FM200 | A2FM250 | |||
Displacement | Vg | cm3 | 125 | 160,4 | 180 | 200 | 250 | ||
Speed 1) | nmax | rpm | 4000 | 3600 | 3600 | 2750 | 2700 | ||
△p=400bar | Tmax | Nm | 796 | 1016 | 1144 | 1272 | - | ||
