6005 Open Chrome Steel Deep Groove Ball Bearing
- Ningbo&Shanghai
 - T/T L/C D/P D/A Credit Card PayPal

You May Like
Product Details
| Brand Name | BUC, BUC,NCTX | Bore Size | 7, 60 | |
| Outside Diameter | 19, 95 | Model Number | 6005, 6005 ZZ | |
| Precision Rating | P0,P5, P6 | Seals Type | ZZ or 2RS | |
| Number of Row | Single Row | Place of Origin | Zhejiang, China |
Product Description
Specifications
6005 open Chrome steel Deep groove ball bearing:1. samples are free
2. in-stock, short delivery time
3. OEM supplier
6005 open Chrome steel Deep groove ball bearing:
1. Precision grade: P0, P6, P5
2. Vibration level: Z1V1,Z2 V2,Z3V3
3. Hardness: 61 to 64 HRC
4. Packaging: Industrial packing: palstic tubes/outer cartons/pallets
Single box packing: single box/outer cartons/pallets
According to your requirement
5. Technology & QC process: Assembly → Windage test → Cleaning → Rotary Test → Greasing and gland
→ Noise Inspection → Appearance Inspection → Rust Prevention → Product Packaging
6. Service: We offer standard deep groove ball bearings, and we can also manufacture non-standard part as your customized. OEM is available.
Model parameters
The parameters of 6000 seires deep groove ball bearing are described as follows:
| Items | Bore | Outer Diameter | Width | Radius | Load Rating | Ball Complement | Max Runout Speed | Weight (kg) | |||
| OPEN | |||||||||||
| mm | mm | mm | mm | Dynamic | Static | No. | Size | Grease | Oil | ||
| 603 | 3 | 9 | 3 | 0.15 | - | - | 7 | 0.588 | 40000 | 48000 | 0.00092 |
| 604 | 4 | 12 | 4 | 0.2 | - | - | 7 | 2 | 36000 | 44000 | 0.0023 |
| 605 | 5 | 14 | 5 | 0.2 | 1.33 | 0.505 | 7 | 2.381 | 39000 | 46000 | 0.0035 |
| 606 | 6 | 17 | 6 | 0.3 | 2.19 | 0.865 | 6 | 3.969 | 35000 | 42000 | 0.006 |
| 607 | 7 | 19 | 6 | 0.3 | 2.24 | 0.91 | 6 | 3.969 | 34000 | 40000 | 0.008 |
| 608 | 8 | 22 | 7 | 0.3 | 3.35 | 1.4 | 7 | 3.969 | 32000 | 37000 | 0.012 |
| 609 | 9 | 24 | 7 | 0.3 | 3.4 | 1.45 | 7 | 3.969 | 31000 | 36000 | 0.014 |
| 6000 | 10 | 26 | 7 | 0.3 | 4.55 | 1.96 | 7 | 4.763 | 29000 | 34000 | 0.019 |
| 6001 | 12 | 28 | 7 | 0.3 | 5.1 | 2.39 | 8 | 4.763 | 26000 | 30000 | 0.021 |
| 6002 | 15 | 32 | 9 | 0.3 | 5.6 | 2.84 | 9 | 4.763 | 22000 | 26000 | 0.03 |
| 6003 | 17 | 35 | 10 | 0.3 | 6.8 | 3.35 | 10 | 4.763 | 22000 | 26000 | 0.039 |
| 6004 | 20 | 42 | 12 | 0.6 | 9.4 | 5.05 | 9 | 6.35 | 18000 | 21000 | 0.069 |
| 60/22 | 22 | 44 | 12 | 0.6 | 9.38 | 5.02 | - | - | 16000 | 19000 | 0.074 |
| 6005 | 25 | 47 | 12 | 0.6 | 10.1 | 5.85 | 10 | 6.35 | 15000 | 18000 | 0.08 |
| 60/28 | 28 | 52 | 12 | 0.6 | 10.05 | 5.92 | - | - | 14000 | 17000 | 0.098 |
| 6006 | 30 | 55 | 13 | 1 | 13.2 | 8.3 | 11 | 7.144 | 13500 | 16000 | 0.116 |
| 60/32 | 32 | 58 | 13 | 1 | 12.47 | 7.24 | - | - | 13000 | 15000 | 0.129 |
| 6007 | 35 | 62 | 14 | 1 | 16 | 0.3 | 11 | 7.938 | 12000 | 14000 | 0.155 |
| 6008 | 40 | 68 | 15 | 11 | 16.8 | 11.5 | 12 | 7.938 | 10000 | 12000 | 0.185 |
| 6009 | 45 | 75 | 16 | 1 | 21 | 15.1 | 12 | 8.3731 | 8200 | 10000 | 0.231 |
| 6010 | 50 | 80 | 16 | 1 | 21.8 | 16.6 | 13 | 8.731 | 6400 | 7800 | 0.25 |
| 6011 | 55 | 90 | 18 | 1.1 | 28.3 | 21.2 | 11 | 11.112 | 5700 | 7000 | 0.362 |
| 6012 | 60 | 95 | 18 | 1.1 | 29.5 | 23.2 | 12 | 11.112 | 5500 | 6300 | 0.385 |
| 6013 | 65 | 100 | 18 | 1.1 | 30.5 | 25.2 | - | - | 5000 | 6000 | 0.408 |
| 6014 | 70 | 110 | 20 | 1.1 | 38.8 | 31.6 | - | - | 4800 | 5800 | 0.602 |
