Bilberry Extract Equipments Double Jacketed Glass Reactors Suppliers

1. volume:1L 2L 3L 5L 10L 20L 30L 50L 80L 100L 150L 200L(NEW)
2. Reacting temp:-80~300
3. GG17, SS,PTFE sealing,TOPTION Brand
4. University brands designated
5. Explosion-prood device is optional
6. Ac motor,brushless,no sparkle
7. Constant rotationg speed
8. Reflow and distillation system
9.chemical laboratory use
10.reaction mixing vessel


                                         Double Glass Reactor  Jacket glass reactor system

Double Glass Reactor product description

Double glass reactor main sealing parts pure PTFE material, guarantee absolute vacuum system.
Double glass reactor double glass design, inner into reaction menstruum do stirring reaction, interlayer can pass different cold sources (cryoprotectants, hot water or hot oil) do cycle heating or cooling reaction. Setting thermostat conditions, in confined glass reactor, can use require atmospheric or negative pressure conditions conducted stirring response and do reaction solution reflux and distillation is modern Fine Chemical Factory, biopharmaceuticals and new materials synthesized ideal test production equipment.

Toption Glass Reactor product introduction

TOPTION Glass reactor is with double glass design, the inner layer placed reaction solvent can do the mixing reaction, the inter layer can be added with the different hot and cold sources (frozen liquid, hot water or hot oil) to do loop heating or cooling reaction. This jacketed glass reactor can be used to do high temperature experiment(max temperature is 300°C),as well aslow temperature experiment(min temperature is -80°C) and vacuum tests. It is an ideal equipment for chemistry small and medium-sized experiment,bio-pharmaceuticals and new materials synthesis. It also is used for extraction of gold.
The most important is that “the design of TOPTION reactor is unique,which can guarantee experiments of more convenient and safer.
Our factory also can produce the double layer glass reactor, Now, The biggest volume we can only produce cylindrical glass reactor with jacketed is 200L .
The biggest volume we can only produce Spherical glass reactor with single-layer is 250L.

Double Glass Reactor product Key Features:

1. Double glass reactor using VVVF, AC Induction Motor. Speed constant, no brush, no sparks, security staTOPTe, continuous working.
2. Complete glass reactor adopts GG17 high borosilicate glass production good chemical, physical properties.
3. Glass interlayer Interface communication on hot oil through cycle do Heating Reaction, Tung on cryoprotectants can be hypothermia reaction.
4. Can normal temperature reaction, pass last tap namely quickly will reflect heat away.
5. Decentralization material mouth with flange mouth and PTFE valve, container no dead corner detachaTOPTe easy solid materials outfeed.
6. 5 reactor lid, large mouth design easy clean standard mouth socket selectaTOP Te assem TOPT reflux, distillation synthesis device

Double Glass Reactor Parameter:

Double Glass Reactor photos:

Toption Company is specialized in glass reactors as following:

single layer glass reactor 1L,2L,3L,5L,10L,20L,30L,50L,80L,100L,150L,200L, up to new 250L;

double layer glass reactor  1L,2L,3L,5L,10L,20L,30L,50L,80L,100L,150L, up to new 200L;

Three layer glass reactor customized

Glass liquid separator

Vacuum glass Filter

Hydrothermal Sythesis Reactor

High Pressure Reactor

We can also customized glass reactor with rectification column , or with exhaust gas absorption system or Destilador molecular depending or Gold Purification on your requirements.

Welcome for customized glass reactor!!!

Toption------your Top Option

Some design for your reference
