Stainless Steel Dutch Wire Mesh For Filters

FOB Price

US$ 53.86 - 520.98 / Roll

1 Roll(Min. Order)

Port Tianjin Xingang
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China	Material	Stainless Steel Wire
Type	Wire Cloth	Application	Screen
Weave Style	Dutch Weave	Wire Diameter	0.02mm-5.5mm
Technique	Woven	Model Number	ADM NO.35
Brand Name	AOYUAN

Product Description

Material: stainless steel wire, nickel wire, brass wire.

Weaving ways: Dutch Plain Woven, Dutch Twill Woven, Reverse Dutch Woven, Five-harness Woven

plain weave :similar to twill Dutch weave, except that the weave is plain, allowing a double layer of weft wires. There are no apertures in the true sense of the word as the filtrate follows a sinuous path through the depth of the wire mesh.

Usage: this type of cloth is most frequently used for high pressure filtration processor to separate from other medium. it is widely used in industry of spaceflight, petroleum, chemical and so on.

Mesh: 20/270 to 500/3500.

Plain Dutch
Gauge	Mesh	Wire Diameter	Reference Values Of Darticles Passed
40	10*64	0.55*0.42	260
50	12*75	0.45*0.35	220
80	24*110	0.35*0.25	160
100	25*140	0.28*0.20	100
120	30*150	0.25*0.18	80
140	35*180	0.20*0.16	70
160	40*200	0.18*0.13	60
180	45*220	0.16*0.12	56
200	50*250	0.15*0.11	50
240	60*300	0.14*0.09	45
260	65*320	0.13*0.08	36
280	70*400	0.125*0.07	34
300	80*700	0.11*0.039	32

Twilled Dutch
Gauge	Mesh	Wire Diameter	Reference Values Of Darticles Passed
80	20*250	0.28*0.2	38
120	30*300	0.25*0.18	36
200	50*500	0.14*0.11	34
320	80*700	0.11*0.08	32
320	80*780	0.10*0.07	30
360	90*780	0.10*0.07	25
400	100*780	0.10*0.07	22
400	100*900	0.10*0.063	20
500	120*1100	0.07*0.05	17
630	150*1400	0.063*0.04	16
650	165*1400	0.07*0.04	14
685	180*1800	0.063*0.032	13
795	200*1400	0.07*0.04	12
795	200*1800	0.05*0.032	10
850	210*1900	0.045*0.03	10
1000	250*2000	0.045*0.028	8
1125	280*2200	0.036*0.026	7
1200	300*2200	0.036*0.026	6
1250	325*2300	0.035*0.025	5
1600	400*2800	0.03*0.018	3

We are producing and exporting various kinds of dutch wire mesh of all sizes and specifications and our products enjoy high popularity all over the world just because of the advanced equipment,perfect craftsmanship ,and scientific inspection skill , reasonable price ,and reliable quality!

Welcome to establish business relations with us !

We assure you we would provide the products with the best quality at the best price for you !
