Specifications

  2014 animal feed pellet machinefor chicken cage

Specifications

Automatic feeding system

 1. Easy operate

 2. Easy maintain

 3. Low cost, high profit

 4. Low noisy

Ancillary products

Pressure reducing valve, vacuum tank, medicine, clean water filter

structure declaration

1. The transverse conveying ground dragon.Twisted dragon outer barrel made of 2 mm thick steel tube, a diameter of 140 mm, twisted dragon made from 2 mm thick steel plate stamping, have the effect of feed to hopper.
2. The hopper.Made of 8 mm galvanized sheet, have the effect of material stock.
3. The control box.Contains a list of the remote control switch and walking speed, have the effect of control equipment to stop walking.
4. Walking mechanism.Including walking walking an axle and wheel, an axle choose 3 mm x 5 mm square steel, walking wheels made of 45 # round steel.
5. Walking speed regulating motor and gear motor.Speed regulating motor can adjust the speed and uniformity of blanking, deceleration motor control equipment of walking.
6. Lifting ground dragon motor.With a 1.1 kw motor, can play the role of to wring dragon rotary feeding.
7. Feeding machine bracket.Made of 4 * 6 square steel, thickness of 2 mm, have the effect of fixed support and attachment.
8. Lifting transport ground dragon.Hank dragon outer barrel made of 2 mm thick steel tube, a diameter of 140 mm, twisted dragon made from 2 mm thick steel plate stamping, have the effect of feed to transport ground dragon.

Automatic feeding machine technology features

1. Saving time and energy, and efficient.From feeding - storage - points and material feeding, realize the whole process automation, and effort very much.Its efficiency is artificial feeding 20-30 times, using artificial feeding, a hen house every time feed usually need to 2-3 hours, and the automatic feeding machine need only 6 minutes at a time.
2 Uniform feeding.Artificial feeding and traditional feeding machine has the problem of feeding non-uniformity, the machine adopts the unique "helical gear precision feeding device", uniform feeding is very accurate.
3. Healthy breeding.Due to using automatic control, personnel without feeding into the henhouse, reduced the chance of chicken cross infection, is one of the most important for healthy aquaculture engineering technical measures.

Feature:

           As the automatic feeding system, the feeding machine distributes the feedstuff evenly with lower noise and saving the energy. It is very strong with durable useful time and to adjust the amount of the feed-stuff freely thus the feedstuff and the feeding time are both saved. the feeding machine runs smoothly with a high speed and walking automatically. The feeder is conveyed automatically and working in a fixed time. The amount of the feeder can be adjusted freely. And the spare parts are all accord with the standards of our country. So it is possess a good performance with a long time utilizing. Tow rows, three rows, four rows, five rows, six rows and seven rows are available for choice including 3 tiers and 4 tiers cage. We design the A type and H type feeding machine to fit the cage A or cage H so the working efficiency is improved greatly.

A type egg chicken equipment

         The full automatic feeding machine is an automatic feeding equipment for modern stereo-breeding. Space-type and H-type tiered automatic feeding machines are designed for type A and type H cage rack separately. The full automatic feeding machine can be customized according to the real space condition to meet the different requirements during the process of feeding. All the operations are controlled mechanically and easy to master.

A Type back bucket feeding machine

A type sowing type feeding machine

A ladder type equipment, convenient operation.Firmness and durability.Reasonable structure, low energy consumption

Advantage :

1.Hot-dipped galvanized material,make the durability 15-20 years,never go rustiness.

2.Each row has an independent feeding machine,easy to operate,and the maintenance rate is very low.

3.Full-automatic control,greatly labor-saving,one person can feeding all the birds in 10-15 minutes.
