Home > Products > On Grid Solar Inverter > Triphase 380V 20KW On Grid Solar Inverter Dual MPPT Input IP65 Protection for Monocrystalline and Polycrystalline Silicon
Triphase 380V 20KW On Grid Solar Inverter Dual MPPT Input IP65 Protection for Monocrystalline and Polycrystalline Silicon
- 1000 Set / Sets per Month
- Shanghai
- T/T D/P D/A Credit Card PayPal
You May Like
-
5KW Solar Inverter Single Phase for Rooftop Solar System Solis Brand High Quality Solar Inverter
-
4600W Single Phase 220V String Inverter Solis Brand High Quality
-
3.6KW On Grid Rooftop Solar Inverter String Solar Inverter 3600W Solis Brand
-
Single Phase Solar Inverter 1500W for Rootop Solar System Dual MPPT Inverter
-
String Inverter 1000W Solis Brand High Quality Solar Inverter for Home Rooftop
-
Home Rooftop Solar Inverter 3KW Single Phase Inverter Solis Brand Grid Tied
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Solis | |
| Model Number | Solis-20K-HV | Specification | Normal | |
| Application | Commercial | Output Voltage (V) | 480Vac | |
| Solar Power (W) | 15000Wp |
Product Description
Triphase 380V 20KW On Grid Solar Inverter Dual MPPT Input IP65 Protection for Monocrystalline and Polycrystalline Silicon
Powerician, a professional solar PV solution provider and solar PV products supplier here offer Solis brand on grid solar inverter.
High qualilty, good reputation, beautiful price.
Here with Powerician, you will get more than you paid for.
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
Features
- Dual functional for both solar PV and wind turbine
- Extral wide input range
- Advancec MPPTalgorithm
- Full protection
- High efficiency
- RS485,GPRS,Wifi,mobile phone APP monitoring supported
Electrical Data
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
| Model No. | Solis-6K | Solis-10K | Solis-15K | Solis-20K-HV |
| Input | ||||
| Max Input Power | 6.9KW | 11.5KW | 15KW | 23KW |
Max Input Voltage | 1000V | |||
Start Voltage | 330V | |||
| MPPT Voltage | 200~800V | |||
| Max Input Current | 15A+15A | 18A+18A | ||
| MPPT/String | 2/2 | 2/4 | ||
| Output | ||||
| Rated Output Power | 6KW | 10KW | 15KW | 20KW |
| Max Output Power | 6.6KW | 11KW | 15KW | 20KW |
| Rate Grid Voltage | 380/400Vac | 480Vac | ||
| Grid Voltage Range | 313~470V Adjustable | 384~576V Adjustable | ||
| Rated Grid Frequency | 50/60Hz | |||
| Grid Frequency Range | 47~52Hz or 57~62Hz | |||
| Phase Quantity | 3 Phase | |||
| Max Output Current | 10.0A | 16.7A | 25A | 25.1A |
| Output Power Factor | >0.99 | |||
| THD | <3% | |||
| Grid DC Component | <20mA | <50mA | ||
| Max Efficiency | 98.2% | 98.3% | ||
| European Efficiency | 97.3% | 97.5% | ||
| MPPT Efficiency | 99.9% | |||
| Protection | ||||
| DC Reverse Connection | Yes | |||
| AC Short Circuit | Yes | |||
| AC Output Over Current | Yes | |||
| Output Over Voltage | Yes | |||
| Insulation Resistance | Yes | |||
| RCD Testing | Yes | |||
| Surge Protection | Yes | |||
| Grid Mornitoring | Yes | |||
| Anti-Island | Yes | |||
| Over Heat | Yes | |||
| Integrated DC Switch | Optional | |||
Basical Data 20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
| Dimension | 430*600*220mm | |||
| Weight | 27kg | 30kg | ||
| Topology | Transformer Less | |||
| Self Consumption | <1W At Night | |||
| Working Environmental Temp. | -25~+60°C | |||
| Working Environ.Humidity | 0~95% | |||
| Protection Level | IP65 | |||
| Noise | <30dBA | |||
| Cooling | Natural convection | |||
| Max.Working Elevation | 2000m | |||
| Design Life Span | 20Years | |||
| Grid Connect Standard | EN50438,G83/2,AS4777,VDE0126-1- | |||
| Safty Standard | EN61000-6-1:2007,EN61000-6-3:2007,IEC62109-1/2;AS3100;NB/T32004 | |||
Interface
| DC | MC-4 Terminal |
| AC | IP67 Connector |
| Display | LCD 2*20Z |
| Communication | RS485,Wifi,GPRS(optional) |
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
Communication
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
WIF/ GPRS for single inverter
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
For more than one inverter
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
20KW 380V On Grid Solar Inverter Solis Brand 20kw Inverter 3 Phase
ALL DATA FOR REFERENCE ONLY.
THE CONTENT HERE IS NOT NECESSARILY TAKEN AS CONTRACT CLAUSE.
POWERICIAN RESERVERS THE RIGHT TO MODIFY ANY DATA WITHOUT PRIOR NOTICE.
PHOTOS ARE AUTHORIZED BY GINLONG TECHNOLOGIES PLEASE DO NOT COPY.
POWERICIAN ALL RIGHTS RESERVED DO NOT COPY WITHOUT PERMISSION.
