Product Details
Place of Origin | Zhejiang, China | Brand Name | GINLONG/Solis | |
Model Number | Solis-4.6K-2G-US | Specification | Normal | |
Application | Home | Output Voltage (V) | 208/240V | |
Solar Power (W) | 4600Wp | Work Time (h) | 8hrs |
Product Description
Residential Solar Inverter US Standard 4.6KW High Quality Inverter Solis brand
Ginlong is a top brand solar inverter from China with high quality and excellent reliablility.
Powerician, authorized distributor of Ginlong, supply full range of Ginlong solar inverter, from 700W to 30kW.
Also, we provide whole on-grid solar power system solution with Ginlong inverter and our high quality solar panles, brackets, wires etc.
Now US standard on grid inverter provide warrantee of 10 Years!
Features
- Extral wide input range
- Advancec MPPTalgorithm
- Full protection
- High efficiency
- RS485,GPRS,Wifi,mobile phone APP monitoring supported
Electrical Data
Model No. | Solis-4K | Solis-4.6K | Solis-5K |
| |||
DC Input | |||||||
Max. Input Power | 4.6kW | 5.3kW | 5.8kW |
| |||
Max. Input Voltage | 600V | ||||||
Start-up Input Voltage | 120V | ||||||
MPPT Voltage Range | 100~500V | ||||||
Max. Input Current | 15A+15A |
| |||||
MPPT Number | 2 | ||||||
Max Inputs String Number | 2 | ||||||
|
| ||||||
AC Output | |||||||
Rated Output Power | 4kW | 4.6kW | 5kW |
| |||
Max. Transient Power | 4.4kW | 5kW | 5kW |
| |||
Max. Output Current | 21A | 23.8A | 23.8A |
| |||
Power Factor | >0.99 | ||||||
Total Harmonic Distortion(THD) | <3% | ||||||
DC Injection Current | <20ma | ||||||
Grid Frequency Range | 47~52Hz/57~62Hz(adjustable) | ||||||
Rated Grid Frequency | 50/60Hz | ||||||
Rated Grid Voltage | 220/230/240V | ||||||
Grid Voltage Range | 180~270V(adjustable) | ||||||
Operating Phase | Single | ||||||
|
| ||||||
Efficiency | |||||||
Max. Efficiency | 97.8% | ||||||
EU Efficiency | 97% | ||||||
MPPT Efficiency | 99.9% | ||||||
|
| ||||||
Protection | |||||||
| DC Reverse-Polarity Protection Output Over Current Protection Output Over Voltage Protection Insulation Resistance Monitoring Residual Current Detection Surge Protection Grid Monitoring Island Protection Temperature Protection Integrated DC Switch Optional | ||||||
General Data | |||||||
Dimension | 339W*565H*172.5D mm | ||||||
Weight | 14.5kg | 16.5kg | 16.5kg | ||||
Topology | Transformer less | ||||||
Self-Consumption | <1W(Night) | ||||||
Operating Ambient Temperature Range | -25~+60°C | ||||||
Ingress Protection | IP65 | ||||||
Noise Emission (Typical) | <30DB | ||||||
Cooling Concept | Natural Convection | ||||||
Max. Operation Altitude | 2000M | ||||||
Designed Life Time | >20 Years | ||||||
Grid connection Standard | UL1741 G83/2 AS4777 VDE0126-1-1 | ||||||
Relative Humidity | 0~95% | ||||||
Safety/EMC Standard | EN61000-1:2007; EN61000-6-3:2007; IEC62190-1/2;AS3100 | ||||||
|
| ||||||
Features | |||||||
DC Connection | MC-4 Connector | ||||||
AC Connection | IP67 Rated Plug | ||||||
Display | LCD 2*20 Z. | ||||||
Interface | RS485, Wifi/GPRS optional | ||||||
Warranty | 5~10 Years |
Communication
WIF/ GPRS for single inverter
For more than one inverter
ALL DATA FOR REFERENCE ONLY.
THE CONTENT HERE IS NOT NECESSARILY TAKEN AS CONTRACT CLAUSE.
POWERICIAN RESERVERS THE RIGHT TO MODIFY ANY DATA WITHOUT PRIOR NOTICE.
PHOTOS ARE AUTHORIZED BY GINLONG TECHNOLOGIES PLEASE DO NOT COPY.
POWERICIAN ALL RIGHTS RESERVED DO NOT COPY WITHOUT PERMISSION.
