Powerician 110W 18V Poly Solar Panels Polycrystalline Silicon PV Module For 12V Home System Led Lights
US$ 0.4 - 0.7
/ Piece
10 Pieces(Min. Order)
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Powerician Small Poly Solar Panel 85W Polycrystalline Silicon PV Module Solar Cells For Home System Power
-
Powerician 55Wp 18V Mini Solar Panel Polycrystalline Silicon PV Module For 12 V System
-
Powerician 5 Wp 18V PV Module Small Polycrystalline Solar Panel For 12V Battery Home Solar System
-
30Wp 18V Solar Panel Mini PV Module Poly Solar Panels For 12V Solar Power System
-
Powerician 75Wp Mini Solar Panel Polycrystalline Silicon PV Module Home Power System Solar Panel
-
Powerician 50Wp 18V Mini Solar Panel Polycrystalline Silicon PV Module For 12V Solar System
Product Details
| Brand Name | POWERICIAN | Model Number | PSP-110-36P | |
| Material | Polycrystalline Silicon | Size | 1250*680*35mm | |
| Number of Cells | 36 | Max. Power | 110Wp |
Product Description
Powerician 110W 18V Poly Solar Panels Polycrystalline Silicon PV Module For Home System Power
Powerician supply high quality solar panels(solar modules) with compatitive price. Both monocrystalline silicon(mono) and polycrystalline silicon(poly) can be found at Powerician.
OEM service is also provided.
Small quantity order is accepted by Powerician.
We are authorized distributor of solar panles. These panels do not only supplied within the system, but alos supplied as single products.
Product Description
Features:
- Power tolerance (-3%~+3%) ensures the stability of power output
- High conversion efficiency based on leading PV techniques.
- Withstand high wind-pressure and snow load
- Easy to install
- Product insuranced by world leadign insurance company.
- IEC61215,IEC61730,CE,RoHS certificated
- ISO9001 and ISO14001 certificated factory manufactered
Mechanical Specification
| Cell Type | Mono Crystalline |
| Number of Cells | 36 |
| Front Glass | 3.2mm Tempered Low Iron Glass |
| Frame | Clear Anodized Aluminium Alloy |
| Junction Box | IP65 with Bypass Diodes |
| Connector | MC4 compatible |
Electric Parameters
| Max Power at STC(Pmax) | 110W | 90w | 85W | 80W | |
| Short Circuit Current(Isc)-A | 6.46 | 5.81 | 5.49 | 5.17 | |
| Open Circuit Voltage(Voc)-V | 21.6 | 21.6 | 21.6 | 21.6 | |
| Max Power Current(Impp)-A | 5.72 | 5.14 | 4.86 | 4.58 | |
| Max Power Voltage(Vmpp)-V | 17.5 | 17.5 | 17.5 | 17.5 | |
| Power Tolerance | -3%~+3% | ||||
STC-- Irradianc 1000W/m2 Module temperature 25°C AM=1.5
Temperature Characteristics
| Norminal Operation Cell Temperature(NOCT) | 45±2°C |
| Temperature Coefficient of Pmax | -0.48%°C |
| Temperature Coefficient of Voc | -0.34%°C |
| Temperature Coefficient of Isc | 0.037%°C |
System Intergration Parameters
| Max System Voltage | DC 1000V |
| Max Series Fuse | 15A |
| Operation Temperature | -40 to +85°C |
| Number of Bypass Diodes | 1 or 2 |
Demension and Weight
| 110W | 90W | 85w | 80W | |
| Demension-mm | 1250*680*35 | 1130*680*35 | 1070*680*35 | 1010*680*35 |
| Weight-kg | 10 | 9.4 | 8.9 | 8.4 |
Performance Curve
Workshop Tour
LEGAL NOTICE
ALL DATA FOR REFERENCE ONLY.
THE CONTENT HERE IS NOT NECESSARILY TAKEN AS CONTRACT CLAUSE.
POWERICIAN RESERVERS THE RIGHT TO MODIFY ANY DATA WITHOUT PRIOR NOTICE.
POWERICIAN ALL RIGHTS RESERVED DO NOT COPY WITHOUT PERMISSION.
