Home > Products > Pipes and Fittings > HDPE Water Pipe
HDPE Water Pipe
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | DX-ASIA | |
| Model Number | PE80 | Material | PE | |
| Specification | DN20 | Length | 12m | |
| Thickness | 3mm | Standard | ISO |
Product Description
PE80 Water supply pipe
Pressure rating | PN 1.25MPa SDR11 | PN 1.0MPa SDR13.6 |
Outer diameter (mm) | OD×WT | OD×WT |
20 | 20×2.3 |
|
25 | 25×2.3 |
|
32 | 32×3.0 |
|
40 | 40×3.7 |
|
50 | 50×4.6 |
|
63 | 63×5.8 | 63×4.7 |
75 | 75×6.8 | 75×5.6 |
90 | 90×8.2 | 90×6.7 |
110 | 110×10.0 | 110×8.1 |
125 | 125×11.4 | 125×9.2 |
140 | 140×12.7 | 140×10.3 |
160 | 160×14.6 | 160×11.8 |
180 | 180×16.4 | 180×13.3 |
200 | 200×18.2 | 200×14.7 |
225 | 225×20.5 | 225×16.6 |
250 | 250×22.7 | 250×18.4 |
280 | 280×25.4 | 280×20.6 |
315 | 315×28.6 | 315×23.2 |
355 | 355×32.2 | 355×26.1 |
400 | 400×36.3 | 400×29.4 |
450 | 450×40.9 | 450×33.1 |
500 | 500×45.4 | 500×36.8 |
560 | 560×50.8 | 560×41.2 |
630 | 630×57.2 | 630×46.3 |
710 |
| 710×52.2 |
800 |
| 800×58.8 |
900 |
|
|
1000 |
|
