electric Industrial Stretch wrapping machine Palletized Packing Machine

Main performance of electric stretch wrapping machine:

Mass production, production capacity is strong, winding packaging machine at any time in the company has a spot, because we focus, so professional;Quality absolute guarantee, if because of problems caused by product quality problems, 3 months free exchange.Our service tenet: difficult again painstakingly again, don't embarrassed partners.

Technical parameters of electric stretch wrapping machine:

Wrapped around the specifications (500-1600) mm x (500-1600) mm (L * W)
packing height: L:1800 mm H:2500mm
packing efficiency :20-40 per hour
Turntable diameter size: 1650 mm height: 85 mm
Turntable bearing :2000 kg
Membrane systems: pre-stretch film frame, the pre-tension can reach 250%, automatically send membrane, ac speed regulation system
Lifting column double chain structure, lifting speed adjustable frequency conversion
control system: PLC control and the layer number of twisting, adjustable, the height is adjustable
Packaging material: LLDPE stretch film thickness (T) 17-35 um width (W) 500 mm
machine weight: 700 kg
Overall dimensions: 2545 mm * 1850 mm * 2310 mm
Power/voltage: turntable 0.75 kw, membrane 0.35 kw, column 0.37 kw `/ AC220V
Special specifications can be customized

Pictures of electric stretch wrapping machine:
