Apple Grading Line

Technical parameters of the machines:

Production efficiency: 12000 fruits/ hour
Classifying grade: 10 grades(it can increase or reduce)
Grading weight scope: 20-1500g
Rated power: 0.75KW
Power supply: 380V
Dimension: 5.5x2.1x1.1m
Weight: 800kg
Materials: Using food grade stainless steel materials.
Application: for citrus, orange, mango, guava, peach, plum, apple, pear, kiwi and tomato etc. fruits and vegetables grading by weight.

Advantages:

1.High efficiency, high precision, good quality, easy operation, fair appearance, reliable after-sales service---it is widely used for grading citrus, mango, guava, peach, plum, apple, pear, kiwi and tomato etc. and vegetables by weight

 2. Structure: The machine has three institutions; they are the automatic feed system, the weighting system and the separate system. Tetrafluoroethylene is covered onto the working part to make the machine running in low noise and increase the use life. The work face uses stretchy materials to ensure that the fruit in high-speed weighing process will not be damaged.

3. Key technology: Controlled by PLC, and is highly intelligent in weighting and calculation. The operation and maintenance of the machine is easy and laborsaving.

4. Room-saving: Advanced design highly saves your workshop space.

If the device works with our fruit washing and waxing machine, it could finish the process of washing, waxing and weighting.
