Sheep Goat Viscera Removing Transportation Line for Slaughterhouse Plant

Main Steps:

1. Living Sheep/goat V-Type Convey Machine
Which mainly used to conveyliving sheep/goat for hanging , the detaildata as following:
Rated Voltage: 380V/3P/50HZ
Power: 2.2Kw
Capacity: 100-4000sheep/goat per hour
Material: Hot galvanized steel main support, PE conveyedbelt, Stainless steel cover

2. Bleeding and Lifting Roller Table
Which mainly used to receivedsheep when finishedkilling on conveymachine before hangingto the bleeding auto-convey line , the detaildata as following:
Material : completestainless steel

3. Sheep/goat Carcass Processing Over-Head Automatic Conveying Rail
Which mainly used to hanging and convey sheep for killing,bleeding and carcass processing, the detail dataas following:
Motor Power: 3KW
Distance of the hanging frame:160cm
Material: Iron coastrail hanger,Stainless steel orbit, All rest is hot galvanized.

4. Dehider:
This machine mainly used for sheep and goat skin removed, The machine compare is more convenient for controlling and weight is less comparethe old technology, the gear motor and air compress systems teamwork,as normal this machine used for small and middle size sheepand goat abattoir (slaughter), The machine workingwith less noiseand working condition more stated.

5. Sheep/goat Viscera Synchronous Conveying Systems
Which mainly used to reception and transportation red and whitesheep viscera for inspection and appoint place for storage and furtherprocessing and includeviscera reception plate, automatic plat over-turned device,plate sterilizing device.

6. Sheep/goat Carcass Chilling Treatment Unit
When sheep/goat half carcass completecarcass processing and weight then send them to acid treatment room for acid treatment, the acid treatment mainly available to keep muttonfresh and make mutton moretender.

7. Sheep/goat Carcass De-boning And Packaging Unit
Hanging-type de-boning: The sheep/goat carcasshang on convey rail then push it into carcassde-boning unit, the workerspre de-boning when carcasshanging on over head conveyrail, then put mutton on belt conveymachine for complete de-boning, this waymainly used in big andmiddle size sheep/goat slaughtering plant.
