Product Details
| Place of Origin | Fujian, China | Brand Name | Singflo | |
| Model Number | HV serie | Theory | Other, DEF transfer pump | |
| Structure | Diaphragm Pump | Usage | Other, Urea pump | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other, electricity | Pressure | Low Pressure | |
| Application | Other, ADBLUE,UREA,OIL,FUEL,DEF |
packing with strong seaworthy carton
Product Description
Specifications
industrial water pumpContinuous working with low temperature
Max flow 30~50LPM,Self-priming
CE Approved
Singflo 30LPM 12v water pump high capacity/industrial water pump

Function:
* Permanent magnet and continuous duty
* Built-in pressure switch automatically starts and stops pump when faucets is opened and closed
* Self-priming so pump can be located above water tank
* Runs dry for extended periods of time without damage
* Hold excellent motor keep stable temperature of pump
| Self Priming | More than 3 meters |
| Port Size: | Hose tail connection 3/4'' |
| Pressure Max. | 40PSI (2.8Bar) |
| Diaphragm Material | Viton |
| Check valve Made | Viton |
| Voltage: | 12V,24V DC, 115V,220V,230V AC |
| Power: | ON/OFF Switch |
| Body Material(DC) | Polypropylene |
| Body Material (AC) | Aluminium |
| Liquid of application: | Water,oil, Urea, Adblue |
Technical Data:
| Model | Volts | Open Flow | Pressure | Amps | Power | Speed | N.W / G.W |
| dc / ac | gpm (lpm) | Shut Off | (A) | (W) | (rpm) | (kg) | |
| HV-30A | 12 Vdc | 30-35 | 40 psi (2.8 bar) | 15 | 180 | 2800 | 5/5.5 |
| HV-30B | 24 Vdc | 30-35 | 40 psi (2.8 bar) | 7.5 | 180 | 2800 | 5/5.5 |
| HV-30S | 115 Vac | 30 | 25 psi (1.7 bar) | 4 | 460 | 3400 | 6 / 6.5 |
| HV-30M | 230 Vac | 30 | 25 psi (1.7 bar) | 1.5 | 345 | 2900 | 6/6.5 |
| HV-40S | 115 Vac | 40 | 25 psi (1.7 bar) | 4.2 | 483 | 3400 | 6 / 6.5 |
| HV-40M | 230 Vac | 40 | 25 psi (1.7 bar) | 1.8 | 414 | 2900 | 6/6.5 |
| HV-50S | 115 Vac | 50 | 25 psi (1.7 bar) | 4.5 | 518 | 3400 | 6 / 6.5 |
| HV-50M | 230 Vac | 50 | 25 psi (1.7 bar) | 2 | 460 | 2900 | 6/6.5 |

Company Profile
                    YouMe Electric Co., Ltd is a leading company that mainly manufactures and trades precision pumps and flow control components. Since 2010, we have provided innovative, high-quality products with reasonable price for a wide range of fluid control applications. Our product engineers work closely with customers to meet their precise performance requirements: -- We have devoted on adblue /def dispenser system since 2008 cooperating with adblue liquid factories & distributers in Europe & Asia. -- Each product has been tested on functionality and performance, and the flow meters are calibrated piece by piece after complete assembly in workshop before delivery. -- Our new plus-bottled water dispenser design was customized with convenience - the pump automatically shuts off when the water source is depleted, and automatically restart when water is restored. This assures damage free to the appliance when running dry. Our products are widely used in a varity of industries including: Adblue / DEF dispenser, Water Treatment and Purification, Biotechnology (Lab water), Medical, Floor Care, Automotive, Road Construction & Maintenance, Beverage/Foodservice, RV/Marine, Agriculture, and Alternative Energy (Solar & Fuel Cell). We directly base on a factory with OEM in over forty countries, and globally deliver our products on time through our distribution network.
