40TPH Palm Oil Mill Plant Malaysia

40TPH palm oil mill plant malaysia

rsidual:less than 0.6%
warranty:1 year
Function:making palm oil
shipping:supplied
insurance:supplied
advantage:lower costs, energy saving
technology:latest
Min.Order Quantity:1 Set/Sets
Port:Qingdao
Packaging Details:wooden cases special for palm oil mill plant malaysia
Delivery Detail:within 30 days after the paymet

Quick Details

• Condition: New
• Usage: palm oil mill plant malaysia
• Type: palm oil mill plant malaysia
• Automatic Grade: Automatic
• Production Capacity: 1-100TPH
• Place of Origin: Henan, China (Mainland)
• Brand Name: QI'E
• Model Number: PPM
• Voltage: 220V/380V
• Power(W): 18.5KW
• Dimension(L*W*H): 2000x1400x1850mm
• Weight: 15TONS
• Certification: ISO CE BV SGS
• After-sales Service Provided: Engineers available to service machinery overseas
• equipment mame: palm oil mill plant malaysia
• raw material: palm fruit bunch
• markets available: Africa, America, Asia
• rsidual: less than 0.6%
• warranty: 1 year
• Function: making palm oil
• shipping: supplied
• insurance: supplied
• advantage: lower costs, energy saving
• technology: latest

Packaging & Delivery

40TPH palm oil mill plant malaysia

palm oil mill plant malaysia

Projects we have done:

1TPH palm fruit processing lines

3TPH palm fruit processing lines

5TPH palm fruit processing lines

10TPH palm fruit processing lines

20TPH palm fruit processing lines

30TPH palm fruit processing lines

40TPH palm fruit processing lines

50TPH palm fruit processing lines

60TPH palm fruit processing lines

70TPH palm fruit processing lines

80TPH palm fruit processing lines

Reception station of palm oil mill plant malaysia

It is used to receipt the palm fruit bunch, and then transport the bunch to the sterilizing tank.The reception adopts hydraulic control system,realizing the automatic operation,which reduces the labor needed a lot.

Sterilization station of palm oil mill plant malaysia

The sterilizer works with direct steam, the steam can weaken the activity of the enzyme, prevent it getting rancid, ensure the good quality of the crude oil. At the same time, it is good for the following treshing processing. We have designed both horizontal and vertical sterilizer, for larger and smaller line.

Treshing station of palm oil mill plant malaysia

The rotating of the drum in the tresher can separate the fruit from the bunch. The fruit will be conveyed to the digester through elevator, and the empty bunch will be conveyed to the outside part through scraper conveyor. The spindle adopts once forging technology, which can make the equipment more solider and durable. At the same time, we have already designed the non spindle tresher, which is driven by the link chain. It can save the producing cost in a large scale.

Pressing station of palm oil mill plant malaysia

The digester is used to adjust the moisture and temperature of the fruit,finally it can increase the oil extraction rate. The digester adopts liquid level control system, which can distribute the material all by itself. To realize the automatic working. The presser adopts hydraulic control system to adjust the distance of different pressing worms, it is applicable to different kinds of palm fruits, and it can ensure the high oil extraction rate.

Clarification station of palm oil mill plant malaysia

Using the latest technology, under the condition of ensuring the good quality of the oil, reduce the equipment cost as much as possible, reduce the loss of the oil, in the practical producing ,the new technology can make the loss of oil less than 1.3%.

Kernel recovery station of palm oil mill plant malaysia

We do use air flue system to separate the shell from the kernel. At the same time, we do adopt unique mud bath equipment to do the separating according to the different gravity of the shell and kernel. Which has higher separating rate.

Oil tank of palm oil mill plant malaysia

water treatment of palm oil mill plant malaysia

power station of palm oil mill plant malaysia

bolier station of palm oil mill plant malaysia
