Home > Products > Concrete Batching Plant > China 240m3/h Skip Type Concrete Batching Plant With Good Quality
China 240m3/h Skip Type Concrete Batching Plant With Good Quality
- Tianjin Shanghai Qingdao
- T/T Credit Card
You May Like
-
Dry Mix Professional Concrete Batching Plant for Mixing Concrete
-
Chinese Central Large Mix Concrete Batch Plant for Best Selling
-
High Effective Modular Concrete Batching Plant With Best Quality
-
25m3/h Bucket Type Concrete Batching Plant for Hot Slae
-
Low Cost Hopper Lift Concrete Batching Plant With Full Automatic Control
-
Ready-mixed Beton Batching Plant
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Henan, China | Brand Name | Reno | |
| Model Number | HLS240 | Power(W) | 210kw | |
| Weight | 80t | Certification | ISO9001:2008 | |
| Warranty | One year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.unifom mixing2.Accurate weighing
3.Belt conveyor with fast conveying
4.skip type concrete batching plant
Brief introduction of China 240m3/h skip type concrete batching plant with good quality
240m3/h belt conveyor concrete batching plant is a set of materials storage, metering, mixing in one of the large concrete mixing equipment, productivity, supporting the host using the twin-shaft compulsory mixer, It can mix various types of concrete.
Main components Host mixer JS3000
Scaleboard and mixing blades is good,special shaft end seal,longer service life
Supporting batching machine PLD6400
The excellent performance of load cell, weighing accurate and stable.
Cement silo Easy to delivery, operated easily
Screw Conveyor of 240m3/h concrete batching plant
high rotation speed, large feeding quantity
Control system
Alternative operating models,automatic,semi-automatic and manual
Parameters of China 240m3/h skip type concrete batching plant with good quality
Type | HLS180 | HLS240 | ||
Theoretical Production (m3/h) | 180 | 240 | ||
Mixer | Type | JS3000 | JS4000 | |
Power (kw) | 2X55 | 2X60 | ||
Discharging Capacity (m3) | 3 | 4 | ||
Aggregate Diameter (mm) | 80 | 80 | ||
Aggregate Bin (m3) | 30 | 40 | ||
Belt Conveying Capacity (t/h) | 650 | 750 | ||
Weighing Accuracy | Aggregate (kg) | 3000±2% | 3500±2% | |
Cement (kg) | 1800±1% | 2000±1% | ||
Fly Ash (kg) | 500±1% | 500±1% | ||
Water (kg) | 800±1% | 800±1% | ||
Additives (kg) | 80±1% | 80±1% | ||
Total Power (Kw) | 170 | 210 | ||
Discharging Height (m) | ≥3.8 | ≥3.8 | ||
The whole weight(t) | 95 | 80 | ||
Delivery picture of China 240m3/h skip type concrete batching plant with good quality
