Yuhong Dry High Intensity Magnetic Separators For Iron Ore
- Qingdao/Tianjin/Shanghai
- T/T
You May Like
Product Details
| Condition | New | Type | Magnetic Separator | |
| Production Capacity | 40-250t/h | Place of Origin | Henan, China | |
| Brand Name | YUHONG | Model Number | 1230 | |
| Voltage | 380V | Power(W) | 1.5-11KW | |
| Weight | 910-9600 kg | Certification | ISO90001 | |
| Warranty | one year expect wear parts | After-sales Service Provided | Overseas service center available |
Product Description
Specifications
Dry Iron Sand Ore Drum Magnetic Separator :1.Processing Capacity:40-250t/h
2.Magnetic intensity:2000-8000
3.Power:3-11kw
High Quality Dry Drum Magnetic Separator Machinery
1.Dry Iron Ore Drum Magnetic Separator Introduction:
Dry magnetic separator is widely used for the primary separation of 5%~20% low-grade magnetite iron ore or dry powder iron ore, effectively increasing the iron grade before grinding process, reducing the ore beneficiation cost, so the production efficiency can be highly improved. Besides, this equipment can be used for the removal of ferrous elements from powdery or granular materials.
2. Dry Drum Magnetic Separator Working Principle :
Dry magnetic separator is based on the different magnetic properties between the ore minerals to separateeither valuable minerals from non-magnetic gangue or magnetic contaminants or other valuable minerals from the nonmagnetic values. After the ore pulp flow into the chute, the ore particles enter the ore feeding area separately under the influence of the water flowing from the jet pipe. The ferromagnetic particles get together and become magnetic floc on the magnetic field there. After that, the magnetic floc move forwards to the magnetic pole and stick to the rolling cylinder. As the magnetic floc and the cylinder rotate together, the magnetic pole rolls alternately, so the gangue and nonmagnetic particles will be agitated, and fall off to be discarged with the pulp.
3. Dry Drum Magnetic Separator Technical Data :
Model | YH-7518 | YH-9018 | YH-1018 | YH-1021 | YH-1024 | YH-1230 | YH-1530 |
body (diameter*length) (mm) | 750×1800 | 900×1800 | 1050×1800 | 1050×2100 |
1050×2400 |
1200×3000 |
1500×300 |
Capacity (t/h) | 40-50 | 45-55 | 100-120 | 125-145 | 130-180 | 150-220 | 170-250 |
Feed size (mm) | 08 | 08 | 08 | 010 | 010 | 0-10 | 0-10 |
Power (KW) | 3 | 4 | 5.5 | 5.5 | 5.5 | 7.5 | 11 |
Ore humidity (%) | ≤3 | ≤3 | ≤3 | ≤3 | ≤3 | ≤3 | ≤3 |
Rotary speed (r/min) | 34 | 30 | 24.5 | 24.5 | 24.5 | 21 | 18 |
Magnetic intensity (OE) | 2000-8000 | 2000-8000 | 2000-8000 | 2000-8000 | 2000-8000 | 2000-8000 | 2000-8000 |
