2015 Yuhong Small Mini Mobile Diesel Powered Stone Crusher 1-10tones per Hour

Henan Yuhong Heavy Machinery Co., Ltd is the parent company and its branch firms occupy the following areas: basic forging, roasting equipment, construction machinery, mining heavy equipment, environmental protection renewable resources, crushing grinding equipment, loading equipment, education training, network science and technology etc. In addition, there is the agent or representative office in central Asia, the Middle East, Southeast Asia, South Africa, Europe, etc. The Group business involves mining, metallurgy, mineral dressing, chemical engineering, coal, electric power, engineering construction, import and export, agriculture, environmental protection, education, e-commerce and other industries.

 mini mobile diesel  powered stone jaw crusher

Introduction of  Diesel Stone Jaw Crusher :

This diesel powered jaw crusher is mainly used in some places where don't have enough electricity or without electricity. It can do middle or fine crushing for every kind of rocks and stones.

Features of Diesel Stone Jaw Crusher  :

1. It has three tyres in the bottom, easy to move and operate, no need to install it to the ground;

2. Large crushing ratio, uniform particle size products;

3. Pad-style nesting population adjustment devices, and ease of adjustment range, and increase the flexibility of the equipment;

4. Safe and reliable lubrication system, convenient replacement parts, small maintenance workload;

5. Structure is simple, reliable; low operating costs.

6. Energy-saving equipment: stand-alone energy-saving 15% ~ 30%; energy saving of the system is more than doubled;

7. The discharging size of jaw crusher can be adjusted to meet the requirements of different users;

8. Low noise and less dust.

Principle of  Diesel Stone Jaw Crusher

The diesel engine transmits power through belt and belt pulley, drives the swing jaw surround the eccentric  shaft do periodiction. The angle between toggle plate and swing jaw increases when swing jaw moves up, which makes the moving jaw get closes to the fixed jaw. At the same time the material is squeezed, rubbing, grinding and other multiple broken. The angle of Jaw Crusher between toggle plate and swing jaw decreases when swing jaw moves down, the moving jaw of Jaw Crusher moves away from fixed jaw by the pulling of rod and spring, the products after crushing will be discharged from the outlet of Jaw Crusher.

Technical Data of  Diesel Stone Jaw Crusher

High Quality Stone Jaw Crusher for Sale/ Stone Crusher Machinery

Parameter of Jaw Crusher for Sale:
