2013 YUHONG mine grinding tube mill
- 100 Set / Sets per Month
- Main ports in China
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Ball Mill | |
| Product Type | Other, ore dressing | Place of Origin | Henan, China | |
| Brand Name | Yuhong | Model Number | Many different types | |
| Voltage | 380v | Power(W) | 18.5-800kw | |
| Weight | 4.6-137t | Certification | CE&ISO9001 | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.Large application range2.simple structure
nvenient maintenance
4.Large capacity and continuous work
YUHONG mining ball mill
Introduction:
Ball mill is the key equipment for grinding after the crush process, and it is widely used in the manufacture industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics. It also can be used for the dry and wet grinding for all kinds of ores and other grind-able mater
Features:
1.Large application range,simple structure and convenient maintenance.
2.Large capacity and continuous work are very obvious.
3.Barrel lining and grinding media can apply various abrasive materials.
4.Installation and adjustment are very convenient and easy to be operated
Principle:
The ball mill is a horizontal rotating device transmitted by the outer gear. The material are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.
Parameter:
Model |
The chamber speed (r/min) |
Ball Load (t) |
Feed In size (mm) |
Feed out size (mm) | Output (t/h) |
Motor |
Weight (kg) | |
Type | Power ( kw) | |||||||
900 ×1800 | 38 | 1.5 | ≤ 20 | 0.075-0.89 | 0.65-2 | Y2001L-6 | 18.5 | 3.6 |
900 ×3000 | 38 | 2.6 | ≤ 20 | 0.075-0.89 | 1.1-3.5 | Y200L2-6 | 22 | 4.6 |
1200 ×2400 | 35 | 3.5 | ≤ 25 | 0.075-0.6 | 1.5-4.8 | Y250M-6 | 37 | 11 |
1200 ×3000 | 35 | 5 | ≤ 25 | 0.075-0.4 | 1.6-5 | Y280M-6 | 45 | 13.8 |
1200 ×4500 | 35 | 75 | ≤ 25 | 0.075-0.4 | 1.6-5.8 | Y280M-6 | 55 | 14 |
1500 ×3000 | 27 | 8 | ≤ 25 | 0.075-0.4 | 2-5 | Y315M-8 | 75 | 15 |
1500 ×4500 | 27 | 12 | ≤ 25 | 0.075-0.4 | 3-6 | JR125-8 | 95 | 18 |
1500 ×5700 | 27 | 15 | ≤ 25 | 0.075-0.4 | 3.5-6 | JR127-8 | 130 | 21.7 |
1830 ×3000 | 24 | 12 | ≤ 25 | 0.075-0.4 | 4-10 | JR128-8 | 185 | 28 |
1830 ×6400 | 24 | 23 | ≤ 25 | 0.075-0.4 | 6.5-15 | JR138-8 | 210 | 34 |
1830 ×7000 | 24 | 25 | ≤ 25 | 0.075-0.4 | 7.5-17 | JR137-8 | 245 | 36 |
2100 ×6500 | 21 | 31 | ≤ 25 | 0.075-0.4 | 14-26 | JR1-144-8 | 355 | 52.8 |
2200 ×7000 | 21 | 37.6 | ≤ 25 | 0.075-0.4 | 15-28 | JR1-145-8 | 400 | 56 |
2400 ×7000 | 19.1 | 45 | ≤ 25 | 0.075-0.4 | 16-30 | JRL15-8 | 475 | 62.8 |
2700 ×7000 | 18 | 61.8 | ≤ 25 | 0.075-0.4 | 18-35 | JR1-154-8 | 710 | 73 |
