Small self-propelled agricultural sprayer machine

Introduction to agricultural sprayer machine

WT-HZ series self-propelled sprayer adopts a unique and practical wheel that can be used for dry land, suitable for dwarf crop seedling, growing overall control. It can be widely used in large area of soil treatment before sowing, seedling herbicides and pest control and so on for crops as soybeans, wheat, rice, potato and plants like herbs, grass, garden flowers. One person per hour could spray3-11 acres, 30 times higher than the motorized sprayers, 100 times than the hand sprayers for the workload.

Technical parameter of  agricultural sprayer machine

 Name: 3WPJSHZ-600 four wheeled amphibious spraying machine

Power: four cylinder diesel engine 55 horsepower firewood

Stall: 3 after the first 2

Walking speed: 0-25 km / h

Operating speed: 8-15 km / h

Operating efficiency: 100-120 mu / h

Fertilization efficiency: 150 mu / h

Fertilization: one side of 10 meters wide

Drive: mechanical drive

Steering: hydraulic power assisted four wheel steering

Gap height: 1.3 meters, height can be customized according to user requirements

Distance: 1.5 meters, can be customized according to user requirements

Tires: model 90-10, 12 cm in diameter, height of 90 cm

Material: glass steel box

Tank volume: 600L

Pump: model B188 four cylinder diaphragm pump

Liquid pump flow: 90L/ minutes

Pressure: 0.3-0.5mpa

Mixing method: high pressure mixing

Filtration system: four stage filtration

Speed: 550 rpm

Spray width: 12 meters, 2+1 segment folding, can be customized

Spray rod height: 0.5---1.5 meters, special height can be customized

Folding of medicine arm: hydraulic automatic folding

Lifting arm: hydraulic lift

Nozzle spacing: 20 cm -70 cm adjustable, special spacing can be customized

Number of nozzles: 24

Spray angle: 110 degrees

Dimensions: 4.1 meters long, width of 2.2 meters, height of 2.4 meters

Machine weight: 1420kg

Select WANTUO, the future success

 Delivery time: Within 5-7 days after receiving clients' payment

Payment Terms:T/T L/C Western Union D/P D/A Escow Paypal

Packing: wooden box free of agricultural sprayer machine

Quality Guarantee: Our Quality guarantee term is for one year, Malfunctions which are caused by operation mistakenly will be responsible for customers

1 Quality guarantee

1 Agricultural sprayer machine

2 Alibaba Assessed Gold Supplier

3 100% Quality control before forwarding

4 Competitive price withe best quality and service

2 Alibaba Assessed Gold Supplier

3 100% Quality control before forwarding

4 Competitive price withe best quality and service

 1 Are you manufacturer?

Yes we are the manufacturer and welcome to visit our factory

2 Can you change the machine voltage as our request

Yes we can change the machine voltage as customers’ request

3 How about your after-sale service

Our engineer can go outside to install and train your workers to operate the full machine line

4 Warranty time of your machine

2 years warranty time except for consumable spare parts

5 How about delivery time of your machine

Generally it needs 5-7 days, for big machines or producing line, it will be much longer but within our negotiated delivery time
