SDG - BURNING BOTTOM / LOW-TOP
- 0 per Month
- GDYNIA
You May Like
Product Details
| Condition | New |
Product Description
Steel boilers SDG Falcon series (with manual fuel system low pass / low-top) are designed for water heating systems in houses, farms and farm buildings and retail outlets.
The fuel is firewood leafy, not exceeding 20% humidity or coal nut assortment. Aqueous body cuboid is made of boiler steel having a thickness of 5 mm (for the elements having contact with the flue gases) and 4 mm (for other elements). SDG series boilers are equipped with water and grate stoker.
Stoker available in models for SDG-32 (inclusive)
Boilers are designed exclusively for use in water systems CO open system with gravity or forced, having safeguards that comply with the requirements. The highest water temperature must not exceed 95 ° C. Maximum operating pressure is 1.5 bar.
SDG series boilers can be installed blower kit or draft regulator.
Parameter | Unit | BOILER MODEL | ||||||
SDG-11 | SDG-13 | SDG-16 | SDG-19 | SDG-25 | SDG-32 | SDG-38 | ||
Nominal heat output *** | [KW] | 14 | 16 | 19 | 23 | 30 | 40 | 45 |
Nominal heat output ** | [KW] | 11 | 13 | 16 | 19 | 25 | 32 | 38 |
Minimum heat output ** | [KW] | 3.5 | 4.0 | 4.5 | 5.3 | 6.8 | 8.3 | 10.0 |
The minimum power Heat *** | [KW] | 4.2 | 4.8 | 6.0 | 7.2 | 9.6 | 12 | 14.4 |
Required chimney draft | [Pa] | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
Max. boiler water temperature | [° C] | 95 | 95 | 95 | 95 | 95 | 95 | 95 |
Max. water pressure in the boiler | [Bar] | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
Thermal efficiency | [%] | ≤ 83 | ≤ 83 | ≤ 83 | ≤ 83 | ≤ 83 | ≤ 83 | ≤ 83 |
Boiler heating surface | [M 2 ] | 1.4 | 1.65 | 1.75 | 1.85 | 2.15 | 2.40 | 2.9 |
Combustion for Q n | [H] | > 2 | > 2 | > 2 | > 2 | > 2 | > 2 | > 2 |
Fuel consumption at rated power nominal ** | [Kg / h] | 4.11 | 5.1 | 6.1 | 7.12 | 9.1 | 10.2 | 13.45 |
Fuel consumption at rated power minimum ** | [Kg / h] | 0.8 | 1.2 | 1.8 | 2.41 | 3.0 | 3.6 | 4.41 |
Fuel consumption at rated power nominal *** | [Kg / h] | 2.5 | 2.8 | 4.2 | 5 | 5.6 | 7.0 | 8.0 |
Fuel consumption at minimum power *** | [Kg / h] | 0.7 | 0.8 | 1.3 | 1.5 | 1.7 | 2.1 | 2.7 |
Water Capacity | [Dm 3 ] | 41 | 49 | 53 | 62 | 69 | 76 | 90 |
Diameter flue | [Mm] | 180 | 180 | 180 | 180 | 180 | 180 | 180 |
The height of the flue | [Mm] | 650 | 750 | 750 | 750 | 850 | 900 | 950 |
Dimensions Hopper | [Mm] | 250x200 | 300x200 | 300x225 | 350x250 | |||
Boiler weight | [Kg] | 190 | 225 | 235 | 255 | 280 | 295 | 345 |
DIMENSIONS | ||||||||
Width | [Mm] | 415 | 415 | 415 | 465 | 465 | 465 | 515 |
Height | [Mm] | 800 | 900 | 900 | 900 | 1000 | 1050 | 1100 |
Length | [Mm] | 840 | 840 | 900 | 900 | 900 | 960 | 1020 |
Firewood ** about 1500 kJ / kg and a relative humidity not exceeding 20%
Coal *** assortment OI
Stoker available in models for SDG-32 (inclusive)
