DIG01029 Multifunctional 5 in 1 Digital Display Tire Gauge/Tire Pressure Measure/Tyre Gauge

Produc Feature

Built-in temperature compensation, ensure accuracy.

LED backlight, headlight ensure accurate reading at night.

Firm structure, comfortable touch.

3 system pressure unit can be changed freely, it is suitable for all vehicles.

Power save mode: turn off within 90s, ensure 3 years battery life.

Measuring unit can be changed among PSI, Bar, kPa

Introduction

Function 1:

Digital Tire Pressure Gauge: (measuring range:0-150PSI, accuracy:±1%)
1.Push “ON” up to turn on, waiting for 2s till LCD displays 0.0PSI. Then push again to change 3 kinds of air pressure units PSI, BAR, KPA, to choose your required one.

2.Aiming the admission piece to tire valve core and press tightly.

3.Keep the status of air-proof for 1-2s, take off tire pressure gauge.

4.Tire pressure will lock and show on LCD display screen in the form of numbers, can be readed intuitively.

Push “ON” button to measure pressure and change among 3 kinds of units.

Tire pressure gauge set to turn off automatically after 90s, or push up and press for 3s.
Before measuring, we advise you to know the standard tire pressure from car manufacturer, or read the user manual. Normally manufacturer will also paste standard tire pressure nameplate in the inner side of car door frame, side of instrument desk, under door lock, on the fuel tank cap, engine compartment and other positions.

Function 2:

flashlight:

Press “flashlight” button to light in the dark.
Highlight LED with concentrated cup to provide more efficient brightness and energy saving.

Function 3:

escape safety hammer:

Crack open the car window to escape under emergency.
High strength and hardness iron hammer.
Better handle design, more stress.
Side anti-skidding rubber pad, won’t slip out of the hand.

Function 4:

seatbelt cutting knife:

Cut the seatbelt to escape when it is locked under emergency.
Note:
1.Don’t use for other purpose, keep the blade sharp.
2.Please don’t let the child under 5-year old to touch, invoid hurting its fingers.

Function 5:

tire depth gauge:(accuracy: ±0.2mm)

1.Push “ON” up to turn on the product, wait for 2s and LCD displays 0.0PSI.
2.Push “ON” down, push out the tire thread gauge.
3.Insert tire thread gauge into tire thread straightly, LCD display will show realtime tire thread depth.

Application

Package

       Standard plastic bags and cartons, also we can provide customized design for all kinds package.

    Production Line

       Our factory management is in accordance with international 5S standards, strict requirements and supervision of the various production processes.

 Latest Exhibitions

We attended the Electronica in Germany in Nov 2014, new products have won the praise of many buyers.
