Model

GD-1004

Engine

Model

4MC-T61

Rated power (KW)

73.5

Rated speed (r/min)

2300

Fuel consumption (g/Kw.h)

≤242.00

Oil consumption (g/Kw.h)

≤1.63

Dimension

Type

4*4

Rated Traction(KN)

21.8

Overall Dimensions

4225 * 2085 * 2925  (with suspension)

L*W*H (mm)

Wheelbase(mm)

2195

Tread(mm)

Front Wheel

1620

Rear Wheel

1620 (adjustable 1620-2020)

Min.Ground Clearance(mm)

370

Radius of Turning Circle(m)

4.3±0.3

Constructional weight  With cab(Kg)

3880 (with cab) / 3580(without cab )

Slow-

2.31-8.03 (normal) / 0.46-1.61(with creeper-gear)

Design speed (km/h)

gear

High-

10.04-34.85(normal) / 2.01-6.97(with creeper-gear)

gear

reverse-

3.10-10.78 (normal) / 0.62-2.16(with cheeper-gear)

gear

Separate Type

straight gear column gear, with changing shifts outfit

Clutch

clutch (ingle disc, dry-type, dual stage, butterfly's shape spring is compressed tightly, independent operation)

Gearbox

4 X (2+1)Compound ; Straight gear and shift by mesh sleeve if with cheeper-gear

Central Drive

Curved tooth bevel gear

Differential

Closed, 4 planetary gear

Front differential

Closed, 2 planetary gear

Differential Lock

mesh sleeve type

Front final drive

Single differential planetary cone gear type

Rear final Drive

Transmission

Wheel

Front Wheel Tire

11.2-24

Rear Wheel Tire

16.9-34

Steering

Steering Type

Independent form, the all-hydraulic front wheel changes direction.

Steering gear

The all hydraulic power steering BZZI-E1000C

PTO

TYPE

Rear positioned, unattached, 35 type, 21 teeth

(R/min)

540/1000 (Optional: 760/1000)

Rated Speed

Max lifts capacity at the point of 610mm from suspending shaft backward (KN)

≥16

Provide specification, photos, and delivery cost for you.

Answer your questions and solve your problems at any time.

12months warranty for the machine without wearing parts.

We will deliver damaged parts (except wearing parts) for free based on quality problem within warranty period.

Wearing parts are also sold to match your machine if needed.

If some parts damaged, please take photos and shoot video firstly, please send us in time.

We will pass your problems to our after-sale department to deal with.

Solution will be provided for you as soon as possible.
