Model

GD-1000

Engine

Model

4MC-T61

Rated power (KW)

73.5

Rated speed (r/min)

2300

Fuel consumption (g/Kw.h)

≤242.00

Oil consumption (g/Kw.h)

≤1.63

Dimensions of

Type

4*4

Tractor (mm)

Rated Traction(KN)

18.6

Overall Dimensions

4225 * 2085 * 2925  (with suspension)

L*W*H (mm)

Wheelbase(mm)

2195

Tread(mm)

Front Wheel

1620

Rear Wheel

1620 (adjustable 1620-2020)

Min.Ground Clearance(mm)

370

Radius of Turning Circle(m)

4.3±0.3

Constructional weight  With cab(Kg)

3880 (with cab) / 3580(without cab )

Slow-

2.31-8.03 (normal) / 0.46-1.61(with creeper-gear)

Design speed (km/h)

gear

High-

10.04-34.85(normal) / 2.01-6.97(with creeper-gear)

gear

reverse-

3.10-10.78 (normal) / 0.62-2.16(with cheeper-gear)

gear

Separate Type

straight gear column gear, with changing shifts outfit

Clutch

clutch (ingle disc, dry-type, dual stage, butterfly's shape spring is compressed tightly, independent operation)

Gearbox

4 X (2+1)Compound ; Straight gear and shift by mesh sleeve if with cheeper-gear

Central Drive

Curved tooth bevel gear

Differential

Closed, 4 planetary gear

Front differential

Closed, 2 planetary gear

Differential Lock

mesh sleeve type

Front final drive

Single differential planetary cone gear type

Rear final Drive

Transmission

Wheel

Front Wheel Tire

11.2-24

Rear Wheel Tire

16.9-34

Steering

Steering Type

Independent form, the all-hydraulic front wheel changes direction.

Steering gear

The all hydraulic power steering BZZI-E1000C

PTO

TYPE

Rear positioned, unattached, 35 type, 21 teeth

(R/min)

540/1000 (Optional: 760/1000)

Rated Speed

Max lifts capacity at the point of 610mm from suspending shaft backward (KN)

≥16
