Corn Silage Harvester for Sale
- Qingdao
- T/T
You May Like
Product Details
| Condition | New | Application | Corn silage harvesting and chopping | |
| Type | Other, Corn forage harvester, Forage harvesting machine | Drive Type | Gear Drive | |
| Usage | Other, cornstalk harvester | Brand Name | Guangda | |
| Model Number | 4QZ-12/ 4QZ-2800 | Certificate | Other, ISO; CCC | |
| Warranty | 12months |
Product Description
Specifications
Corn silage harvesterSilage corn,sorghum,kenaf,rapier grass ,alfalfa,wheat, forage grass
2.2m/2.8m working width
180hp/220hp
corn silage harvester for sale
- Silage corn,sorghum,kenaf,rapier grass ,alfalfa,wheat, forage grass
- 2.2m/2.8m working width
- 180hp/220hp engine power for optional
A leading factory specailize in manufacturing the silage harvester in vers an area 50 Acres with more than 1500 wokers
This machine' maily used for corn stem ensilage, dry storage harvest (without ear)Does not have to harvest align with the rows of cornCutting, conveyance and feeding fittings can realize reverse turnIt performs cutting, conveyance, being flatten by pressing, cutting into pieces, load on truck during one operation.
Model | 4QZ-12 | ||
Overall dimensions (L*W*H)mm | 7700x2580x3180 | ||
Working width (mm) | 2200 | ||
Working efficiency (ha./hour) | 0.66-1 ha./hour | ||
Cutting stubble height (cm) | ≤15 | ||
Cutting length of stems (mm) | 15-35 can be adjusted | ||
Whole weight (kg) | 5490 | ||
Turning speed of blade shaft | 1330 rpm | ||
Driving cab type | Common type | ||
Working speed (km/hour) | ≤4.5km/hour | ||
Engine model | Rated power (kW/hp) | NC6BZL4-22 | 180HP |
Rated turning speed (rpm) | 2200 | ||
Driving tread mm | 1740 | ||
Turning tread mm | 1650 | ||
Wheelbase mm | 2600 | ||
Minimum passing radius (turning left) | 7220mm | ||
Minimum passing radius (turning right) | 6660mm | ||
Minimum ground clearance (mm) | ≥270mm | ||
The height adjustable range of cutting platform | 1290mm | ||
220HP forage harvester/ silage combine harvester
2.8m working width forage harvesting machine
220hp self-propelled harvester
This machine' maily used for corn stem ensilage, dry storage harvest (without ear)Does not have to harvest align with the rows of cornCutting, conveyance and feeding fittings can realize reverse turnIt performs cutting, conveyance, being flatten by pressing, cutting into pieces, load on truck during one operation.
4QZ-2800 Self-propelled silage harvester | |||
Type | Self-propelled hharvesterharvesterharvester | ||
Model | 4QZ-2800BY | ||
Harvesting width | mm | 2800 | |
Header interval | mm | 550-650 | |
Diesel engine | Model | NC6110ZLN2L | |
Rotate Speed | r/min | 2200 | |
Power | kw | 155 | |
Dimension L*W*H | mm | 6800*3300*3500 | |
Weight | kg | 7200 | |
Grain tank | M³ | 1.3 | |
Unloading height | mm | 1700 | |
Max crossing height | mm | 2620 | |
Mini ground clearance | mm | 330 | |
Minimum turning radius | Left/Right | mm | ≤6500/≤5500 |
Operating speed | Km/h | ≤5 | |
Working productivity | hm²/h | 12kg/s | |
Average oil consumption | kg/hm² | ≤25 | |
Snapping roller | / | horizontal type | |
Peeling roller | / | nylon and rubber | |
Center distance of cutting knife | / | 600 | |
Gearbox | / | mechanical 3+1 | |
Wheel track | front/rear | mm | 1200/1220 |
Tire specification | front/rear | / | 6.50-14/9.5-20 |
Straw smash machine | / | horizontal type | |
24hours online to ensure quick response to customers' inquiry or online message
guide customers to choose the best suitable machine model, offer detailed specification and competitive prices
Contract execution
Machine production will be arranged strictly according to the contract
Machine photos will be sent to you for reference and inspection during production
Machines will be strictly inspected and tested before delivery
Strong enough packages to prevent possible damages during shipping
Send customs clearance documents by DHL
Keep customers to be informed of vessel location while shipping and get them prepared for customs clearance work
After-sale service
12 months warranty except for wear parts
broken spare parts (except for wear parts) will be sent for free due to quality problems
In time response to customers technical problems
New products update for customers' reference
Henan Guangda is a professional manufacturer and supplier of farm machinery, has been engaging in the international trading for 14 years. 12-180hp wheel tractor, agricultural implements and forest machinery are our main production, one-stop service is our main feature. Products are widely exported to North America, Europe, Africa, South America and Southeast Asia. Featuring high quality standards, rigorous management measures and advanced technology, we have built up very fine reputation among both domestic and overseas customers.
1. Free tool box and free easy damage parts
2. Warranty: warranty time is 12 months after the goods delivery your port.
3. Color: according to your requirement
4. Logo: can stick your logos free if you need
5. Delivery time: 25 days after the down payment
6. Payment: The payment term is T/T (30% deposit in advance, 70%T/T as balance before shipment)
7. Various attachments and implements are supplied too for the tractors
8. technical service offered whenever you are in need
