Home > Products > Farm Tractor > JINMA-454 45HP chinese tractors with 4 in 1 Front end loader And A/C Cabin

JINMA-454 45HP chinese tractors with 4 in 1 Front end loader And A/C Cabin

FOB Price

Negotiable / Set

1 Set(Min. Order)

Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Wheel Tractor
By wheel	4WD	Usage	Farm Tractor
Drive Type	Gear Drive	Power(W)	33100
Certificate	CE	Brand Name	JINMA
Model Number	JM-454	Place of Origin	Jiangsu, China
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

JM454 Agricultural Tractor
45hp,4WD farm tractor
EEC/COC, EPA, OECD approved
Turf tyre available

Product Description

Jinma Two-wheel drive or four-wheel drive wheeled tractors ranging from 18HP to 85HP are series tractors which feature large tractive force, low fuel consumption, varied functions, and being easy to operate, wide applications and reliable operations. They are suitable for dry land, hilly land, vegetable farm, orchard and other farm lands or for gardening use or as a motive power. And what is more, they are the ideal means for short distance transportation. Now the Jinma tractor already got the EEC approval as well as U. S. EPA certificate and approved by OECD as well.

JINMA 454(4WD) Four Wheel Tractors Technical Parameters

Tractor Parameters	Model			JM-454
	Drive Type			4WD
	Overall Dimensions LWH(mm):			388016252160
	Wheel Track (mm)	Front		1300
		Rear		1300-1600
	Wheel Base(mm)			1877.5
	Ground Clearance (mm)			325
	Rated Traction Force(N)			11700
	Construction Mass(kg)			2116
	Min.Turning Radius(m)			3.5
	Theoretical Speed(Without creeper) ( km/h)		Forward	2.145,3.150,5.122,6.725,9.632,14.150,23.003,30.203
			Reserve	3.182,4.675,7.600,9.979
	Theoretical Speed(With creeper)(km/h)		Forward	0.321,0.472,0.767,1.007,1.442,2.118,3.443,4.520
			Reserve	0.476,0.700,1.138,1.491
Engine Specifications	Model			490T EPA
	Type			4-Cylinder 4-stroke cycle water cooled
	Rated Power(kw/hp)			33.1/45
	Rated Speed (rpm)			2200
	Bore*Stroke(mm)			90X105
	Total Displacement(L)			3.039
Drive System	Clutch			Single-function dry constant meshing
	Gear Box			4*(2+1)Sleeve gear
	Main Drive			One Pair of Spiral Bevel Gearing
	Differential			Bevel gear
	Differential Lock			Sliding pin,foot operated
	Final Displacement(L)			Planeatry reduction gear
Travelling Mechanism	Tyre	Front		8.3-20
		Rear		12.4-28
	Steering Gear			Hydraulic steering
	Brake			Oil immerszd multiplate disc
Working Device	Hydraulic System	Lifting Capacity at 610mm Behind Lift Pioint (N)		7500
		3-Point Suspension		Category:I
	P.T.O Shaft	Speed (rpm)		540/1000
		Spline Size		6-35Rectangular Spline
OPTIONS				SAFETY FRAME,CANOPY,CREEPER,SHUTTLE,SYNCHRONISED GEAR,CAB
