Best and cheap JINMA tractor from 16-125HP

FOB Price

Negotiable / Set

1 Set(Min.Order)

Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Wheel Tractor
By wheel	4WD	Usage	Farm Tractor
Drive Type	Gear Drive	Power(W)	55000
Certificate	CE	Brand Name	JINMA
Model Number	JM-704	Place of Origin	Jiangsu, China
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

JM704 Agricultural Tractor
70hp,4WD farm tractor
COC, OECD approved
easy operation, high capacity, Iow energy consumption

Product Description

Jinma Two-wheel drive or four-wheel drive wheeled tractors ranging from 18HP to 85HP are series tractors which feature large tractive force, low fuel consumption, varied functions, and being easy to operate, wide applications and reliable operations. They are suitable for dry land, hilly land, vegetable farm, orchard and other farm lands or for gardening use or as a motive power. And what is more, they are the ideal means for short distance transportation. Now the Jinma tractor already got the EEC approval as well as U. S. EPA certificate and approved by OECD as well.

JINMA 704(4WD) Four Wheel Tractors Technical Parameters

Tractor Parameters	Model		JM-704
	Drive Type		4WD
	Overall Dimensions LWH(mm):		408519292568
	Wheel Track (mm)	Front	1450
		Rear	1370-1790
	Wheel Base(mm)		2236
	Ground Clearance (mm)		340
	Rated Traction Force(N)		14500
	Construction Mass(kg)		3190
	Min.Turning Radius(m)		4.3
	Theoretical Speed (With out creeper gear(km/h)	Forward	2.27,4.01,6.45,8.09,9.06,16.05,25.82,32.25
	Theoretical Speed (With creeper gear(km/h)	Reverse	3.15,12.61
Engine Specifications	Model		LR4108T79B
	Type		4-cylinder 4-stroke cycle water cooled
	Rated Power(kw/hp)		51.5(70)
	Rated Speed (rpm)		2200
	Bore*Stroke(mm)		108*125
	Total Displacement(L)		4.6
Drive System	Clutch		Dual stage
	Gear Box		(4+1)*2 Sleeve gear shift
	Main Drive		Onepair of spiral bevel gearing
	Differential		Bevel gear
	Differential Lock		Sliding pin,foot operated
	Final Transmission		Planeatry reduction gear
Travelling Mechanism	Tyre	Front	8.3-24
		Rear	14.9-30
	Steering Gear		Hydraulic steering
	Brake		Disc type
Working Device	Hydraulic System	Lifting Capacity at 610mm Behind Lift Point (KN)	11.6
		3-Point Suspension	Category:II
	P.T.O Shaft	Rotating Speed (rpm)	720 or 540/1000
		Spline Size	6-35Rectangular Spline
OPTIONS			ROLL BAR,CANOPY,CAB,AIR BRAKE
