L099 flexible jaw coupling
USD $1 - $5
/ Piece
100 Pieces(Min.Order)
- 10000 Piece / Pieces per Month
- SHANGHAI NINGBO
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Structure | Jaw / Spider | Flexible or Rigid | Flexible | |
| Standard or Nonstandard | Standard | Material | Steel | |
| Brand Name | MW | Place of Origin | Zhejiang, China | |
| Model Number | L099 |
Product Description
Specifications
L099 flexible jaw couplingAVAILABLE SIZES: 35, 50, 70, 75, 90, 95, 99, 100, 110, 150, 190, 225
L099 flexible jaw coupling
1. Material :Cast iron GG25
2. Good stability
3. Easy to maintain
4.OEM
L coupling have below advantage :
1. It is easy to maintain ,no need the tool can install
2. Can undertake high torque
3. Have the good buffer .
Features:
Economical and practical using
Easy pulling out
Simple construction and light weight
NBR rubber with excellent resistance to oil and drugs
Minimum space
No lubrication
L coupling parameters and data :
| Coupling type | Rated torque | HP-100PRM | |||||||
| In-Lbs. | Horsepower Capacity at Varying Speed(RPM) | Max Bore | |||||||
| Rubber | Hytrel | Rubber | Hytrel | 300 | 1200 | 1800 | 3600 | ||
| L-035 | 3.5 | 0.0056 | 0.017 | 0.067 | 0.1 | 0.2 | 3/8 | ||
| L-050 | 25.2 | 0.04 | 0.12 | 0.48 | 0.72 | 1.44 | 5/8 | ||
| L-070 | 37.8 | 0.06 | 0.18 | 0.72 | 1.08 | 2.16 | 3/4 | ||
| L-075 | 75.6 | 0.12 | 0.36 | 1.44 | 2.16 | 4.32 | 7/8 | ||
| L-090 | 126 | 0.2 | 0.6 | 2.4 | 3.6 | 7.2 | 7/8 | ||
| L-095 | 176 | 0.28 | 0.84 | 3.36 | 5.04 | 10.8 | 1-1/8 | ||
| L-099 | 265 | 0.42 | 1.26 | 5.04 | 7.56 | 15.1 | 1-3/16 | ||
| L-100 | 278 | 0.6 | 1.8 | 7.2 | 10.8 | 21.6 | 1-3/8 | ||
| L-110 | 693 | 2079 | 1.1 | 3.3 | 3.3 | 13.2 | 19.8 | 39.6 | 1-5/8 |
| L-150 | 1071 | 3213 | 1.7 | 5.1 | 5.1 | 20.4 | 30.6 | 61.2 | 1-7/8 |
