Maize Seed Coating Machine
- TIANJIN
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Type | seed coating machine | Use | coating or dressing seed | |
| Certification | ISO9001-2008 | Place of Origin | Hebei, China | |
| Brand Name | SYNMEC | Model Number | 5BY-5B | |
| Condition | New | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
maize seed coating machine
The 5BY-5B maize seed coating machine is very suitable for coating grain seed, such as seed of wheat, barley, maize, sorghum, soybeans, cotton, chili, grass, etc.
Principle:
The maize seeds go into the mixed box through the elevator, then the seeds will evenly spread around by the cone-shaped grain scattering gear, in the scattering process, the medicament will deliver to the centrifugal rotational disk (which in the mixed box) by DOS pump, under the high-speed centrifugal force, medicament will be atomized uniformly and effectively attached to the seed surface, forming an primary coated body, and then the primary coated body go into the blender, that will be mixed round and coated by soft auger, finally exit from the outlet.
Advantages:
High speed centrifugal rotary disk (for atomizing the liquid medicine) and large stainless steel cylinder (for mixing by auger rolling), can have a very good coating effect.
- The Soft Auger in cylinder reduces seed damage when mixing seeds and medicine.
- Measuring pump can adjust the quality and the percentage of the medicine in seeds.
Technical Parameter
Model | 5BY-5B |
Dimension (L*W*H)mm | 2150*800*2400 |
Capacity | 5 T/H (counted by wheat) |
Power | 2.3 KW |
Weight | 700 KG |
Use reliability | ≥98% |
Coating rate | ≥93% |
Breaking rate | ≤0.1% |
You may would like other seed grain processing machine
Destoner (5XQS-5)
Destoners are mainly used in grain cleaning and food processing sector, they are also applied in seed sector especially on crops being harvested close to the ground.
Gravity separator (5XZ-6)
5XZ series gravity separator is used to separate material with in same size but different in specific weight.It can efficiency remove partially eaten, immature, insect damaged, sick seeds from good seeds.To achieve high grading quality of seed, gravity separator become the basic machinery for seed company.
Pre-Sale | Your inquiry will be replied by our well-trained & experienced staff within 12 hours. |
Shipping | By sea with less container load or full container load We will choose or advise the most convenient way for you. |
Payment | We accept T/T, Western Union, MoneyGram, Paypal, L/C(above 30K USD). 30% in advance, balance should be paid before shipment. |
Feedback | We sincerely invite you to leave positive feedback to us. If you have any questions, please feel free to contact us at any time. We will reply as soon as possible. |
After Sale | Any questions of the production, please let me know directly by email or phone. We can deal with these issues on time, promise give you happy answers. We focused on the after sale. Welcome send any comments to us. |
We are an international trading company also a professional manufacturer for grain cleaning and seed processing machinery. Our manufactory’s name is Hebei RUIXUE Grain Selecting Machinery Limit, SYNMEC as an international brand of‘RUIXUE grain selecting machinery’, also it is an independent corporate entity ‘SYNMEC International trading Ltd.’, so we can provide professional machinery making and professional international trading service.
Customers visits
1. Q Are you factory or trading company?
A We are professional manufacturer for seed processing machinery and also a international trading company
2. Q What is your minimum order quantity?
A 1 Set
3. Q What are your payment terms for new customers?
A T/T, L/C, Money Gram, West Union, Paypal etc
4. Q How long will it take for my products to arrive me?
A Usually by sea, 20 days to 50 days depend on which country you are in.
5. Q Do you help to install the machines?
A Yes, no problem
we will send our engineers to take charge of the installation, test running, and training local operators.
6. Q How can I visit your factory?
A1. From Guangzhou Baiyun International Airport to Shijiazhuang international airport (2.5hours) , then to our factory by car (1hour)
A2. From Beijing West Railway Station to Shijiazhuang Railway Station by high-speed train(1.5 hours), then to our factory by car (45minutes)
A3. From Hongkong International airport to Shijiazhuang international airport (4.5hours), then to our factory by car (1hour)
