Mini diesel forklift FD15 for sale CE approve

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Anhui, China
Brand Name	FM	Model Number	FD15
Type	Manual Pallet Truck	Power Souce	Diesel Engine
Rated Loading Capacity	1.5TON	Max. Lifting Height	3000mm
Min. Lifting Height	115mm	Fork Length	920mm
Fork Width	100mm	Overall Dimensions	2250x1086x3860mm
Certification	CE approve	After-sales Service Provided	No overseas service provided

Diesel forklift
Rated capacity: 1.5ton
CE approve
Engine:XINGCHANG485BPG
Power:30KW

		Parameter Name	Unit	FD15	FD18
Speciality		Power model		Diesel	Diesel
		Rated capacity	kg	1500	1800
		Load center	mm	500	500
		Lifting height	mm	3000	3000
		Free lifting height	mm	115	115
		Size of forks (LWH)	mm	92010035	92010040
		Mast tilt angle(Front/Back)	.	6/12	6/12
		Minimum turning radius	mm	2060	2060
		Minimum right-angle stacking aisle width	mm	3680	3680
		Minimum right-angle aisle width	mm	1865	1865
		Minimum ground clearance	mm	105	105
		Overhead guard height	mm	2040	2040
		Front overhang	mm	400	400
performance		Max driving speed (Full load)	km/h	14.5	14.5
		Max lifting speed (Full load/Without load)	km/h	460/500	460/510
		Max tractive force (Full load)	KN	16	16
		Max grade ability	%	20	20
Size		Overall length( No forks)	mm	2250	2250
		Overall width	mm	1086	1086
		Max fork lifting height(With load backrest)	mm	3860	3860
		Mast height	mm	1955	1955
Chassis		Tyre Front wheel	mm	6.50-10-10PR	6.50-10-10PR
		Tyre Back wheel	mm	5.00-8-10PR	5.00-8-10PR
		Axle base	mm	1400	1400
		Wheel span(Front/Back)	mm	890/920	890/920
		Dead weight(No load)	kg	2680	2890
drive	Battery	Voltage/Capacity	V/Ah	12/90	12/90
	Engine	Model		XINGCHANG485BPG	XINGCHANG485BPG
		Rated power	kw/r.p.m	30/2600	30/2600
		Rated torque	Nm/r.p.m	131/1800	131/1800
		Cylinders diameter *Stroke	mm	0.9	85*100
		Number of cylinders		4.0	4.0
		displacement	L	2.27	2.27
Fuel tank capacity			L	45	45
Transmission Gear position Front/Back				2/2 Manual shift 1/1 Power shfit
Working pressure			Mpa	14.5
